Introduction

This guide describes how to install, configure, and operate the Extron FPC 6000 Front Panel
Controller. Unless otherwise stated, the terms "Front Panel Controller," "touchpanel," and "FPC"
refer to the Extron FPC 6000.
The topics covered in this section are:
•
•
•
•

About the FPC 6000

The FPC 6000 uses an Extron TLP Pro 1520M TouchLink touchscreen to provide an intuitive,
15-inch control interface with straightforward menus for quick and easy system configuration.
The FPC 6000 is a stand-alone device that does not require an additional external controller or
configuration with Global Configurator Plus and Professional or GUI Designer software.
The following FOX3 matrix switchers are supported:
•
The FPC 6000 continues to support the following matrices:
•
•
•
•
•
NOTE:

Features

•
•
•
•
•
•
•
•
About the FPC 6000
Features
Application Diagram
Matrix Switcher Terms
FOX3 24X, 40X, 80X, 160X and 320X (as a remote front panel controller)
FOX Matrix 3200
FOX Matrix 7200
FOX Matrix 14400
FOX Matrix 320X
1K Matrix systems (multi- FOX 320X with Mediator)
Additional matrix switchers will be added in the future. See
the most recent information about compatible matrix switchers.
Intuitive, menu-driven 15" color touchscreen control interface
Global presets — FOX3 supports up to 16 Global Presets.
Room Presets— FOX3 supports up to 80 rooms, and for each room, up to 10 room
presets are associated.
Remote monitoring, access, and management of all set-up and control functions
Ethernet capabilities — For matrix control from one or more locations over a local area
network
Multiple matrix control — The controller is capable of storing up to ten IP addresses.
7U, rack-mountable panel — Can also be installed in a control console.
Includes a PI 140 Power Injector — The FPC 6000 receives power and communication
over a single Ethernet cable, eliminating the need for a local power supply.
