Installation
Overview
This section provides an overview of the installation process. Follow the links for a more detailed
explanation of each step.
The FPC 6000 consists of:
•
•
•
1.
2.
3.
(1) 15 inch touchpanel
(1) PoE power injector
(1) 7U high, 19 inch wide, rack-mountable metal panel
Obtain the following network information from your network administrator:
Dynamic Host Configuration Protocol (DHCP) status (on or off). If DHCP is off, you
…
also require:
IP address
…
Subnet mask
…
Gateway
…
User name — By default, this is
…
Password
…
NOTES:
•
The factory configured passwords for all accounts on this device have been set
to the device serial number.
•
If the device is reset to default settings, the password will be the default
password configuration. The default password is extron.
•
To change the password, you must use the Extron Toolbelt utility (see the
Toolbelt Help File). Talk to your Extron rep about obtaining a license for
Toolbelt.
IP address for the matrix switcher
…
Password for the matrix switcher — See the user guide for your matrix switcher for
…
information about the password.
Decide where the FPC 6000 will be mounted (see
Cable the unit:
If you are using the provided PoE power injector, connect the FPC 6000 to the
…
power injector and connect the power injector to the Ethernet LAN (see
page 11).
If you are using a 12 VDC power supply (not provided), connect the FPC 6000 directly
…
to the LAN (see XTP/LAN/PoE input
FPC 6000.
ATTENTION:
• Do not power on the FPC 6000 until you have read the
notifications
• Ne branchez pas le FPC 6000 avant d'avoir lu les
sources d'alimentation (voir page 11).
admin
Passwords are case sensitive.
Mounting
on page 11) and connect the power supply to
about power supplies (see page 11).
FPC 6000 • Installation Overview
on page 6).
figure 6 on
Attention
mises en garde sur les
4
