Display

1
Press the Display button in the navigation panel at the top of the screen to open the
screen.
Figure 11. Display Screen
The Display screen allows you to set the Sleep Timer, Auto Brightness, LCD Brightness,
and Wake on Motion.
Sleep Timer — Determines how long the panel is inactive before it enters sleep mode,
•
when the screen goes dark to save power. Toggle between On and Off. If the sleep timer is
on, use the arrows to adjust the value between 1 and 120 minutes.
Test Pattern — Allows you to go through a series of test patterns to check for dead or stick
•
pixels.
Auto Brightness — Provides a suitable amount of backlighting that is automatically
•
calculated from the amount of ambient light detected by the light sensor (see
on page 9).
LCD Brightness — Allows you to adjust the screen brightness, using the slider control.
•
Wake on Motion — Activates the panel from Sleep mode when motion is detected near
•
the unit. Toggle between
Configuring the Motion Sensor
The Motion Sensor (see
touchpanel, and at least 15° from the center axis.
If the Sleep Timer has been set and no motion has been detected for a user-defined
•
period of time, the touchpanel enters sleep mode.
If the Sleep Timer has not been set, the touchpanel does not enter sleep mode.
•
If Wake on Motion has been set and motion is detected by the sensor while the
•
screen is in sleep mode, the screen display is restored and active.
If Wake on Motion has not been set and the screen is in sleep mode, touch the screen
•
to restore it to an active state.
and .
On Off
figure 4, F ) detects motion between three to five feet from the
Display
figure 4,
C
FPC 6000 • Setup Menu 16
