1
1.
Tap the Matrix IP Address text box to activate it.
An on-screen keyboard opens:
q
w
TAB
1 1
2 2
.?123
Figure 21.
Keyboard
2.
Use the up arrow key (see figure 21,
Use the numbers key (.?123,
numbers.
Use the keyboard key (
3
3.
If necessary, clear existing characters by pressing the text box to the right of the final
character, and then repeatedly pressing the backspace key until all unwanted characters are
removed.
4.
Press the numbers key and use the keyboard to enter the IP address of the matrix switcher.
NOTE:
If you have previously connected to a matrix switcher, the IP address might
already be displayed or may be available in the dropdown menu.
5.
Select the Matrix Type (
6.
If required, press the Password text box and use the on-screen keyboard to enter the
username (by default this is admin) and password for the matrix switcher.
NOTES:
•
The factory configured passwords for all accounts on this device have been set
to the device serial number. Passwords are case sensitive.
•
If the device is reset to default settings, the password is the default password
configuration. The default password is extron.
•
To change the password, you must use the Extron Toolbelt utility (see the Toolbelt
Help File). Talk to your Extron rep about obtaining a license for Toolbelt.
7.
Press Submit.
The FPC 6000 attempts to connect to the matrix switcher. If successful, the
appears (see
figure 23
on the next page).
192.168.254.251
e
r
t
y
u
i
a
s
d
f
g
h
z
x
c
v
b
n
SPACE
1
) to toggle between upper or lower case letters.
2
) to toggle between letters or special characters and
) to hide the keyboard.
) using the dropdown, if it is not set already.
4
o
p
X
j
k
l
m
SUBMIT
.?123
3 3
Ties Screen
FPC 6000 • Operation
23
