Introduction

About the Digital PlenumVault Direct View Systems

The PlenumVault Direct View Systems are easy-to-use, network-enabled, all-inclusive
packages, making them ideal for single-display classrooms. These systems include network
connectivity for web-based asset management, monitoring, and control.
The PlenumVault Direct View System is used in a suspended ceiling room with a wood
or concrete structural ceiling foundation. It uses the PVM 220 PlenumVault Mounting
Kit to securely mount and conceal system components in the plenum space above the
suspended ceiling. If the location has a concrete or beam style ceiling, alternative mounts
can be obtained separately from Extron.
NOTES:

Overview of This Guide

This guide covers the installation of the Extron PlenumVault Direct View System.
It is assumed that the installer has some knowledge and experience of AV, electrical, or
electronic device installation. This guide provides instructions for installing and connecting
each system component.
It may be that the locations for the devices (for example, wallplates, user interface and
display) have been pre-determined. However, some room installation examples are given to
help in installations where final location is yet to be determined.
NOTE: In this guide, where used, the generic term "12 VDC power supply" refers to the
• The hardware and devices listed on the
information, installation, set-up, and configuration instructions which should be
referred to as needed.
•
For operation and setup of the main display and input devices, refer to the relevant
manufacturer manuals supplied with those devices.
12 VDC, 50 Watt, 4.2 Amp power supply ONLY, as supplied by Extron.
Inventory (page 6) have detailed safety
PlenumVault Direct View Systems • Introduction 1
