Circutor Computer SMART III 6 Instruction Manual page 67

Computer SMART III
Capacitive and Inductive Hysteresis
Configuration variable
Capacitive hysteresis
Inductive hysteresis
C/K factor
Configuration variable
C/K factor
Program
Configuration variable
Program
No� of stages
Configuration variable
No. of stages
Connection and reclosing time
Configuration variable
Connection time
Reclosing time
Alarm: Voltage THD
Configuration variable
Low Value
Hi Value
Alarm: Current x I THD
Configuration variable
Low Value
Hi Value
Alarm: Temperature
Configuration variable
Low Value
Hi Value
Alarm: Leakage Current
Configuration variable
Search for the responsible stage
Value
Stages enabled
Instruction Manual
Table 24: Modbus memory map: programming variables (Table 9)
Address
1185
1186
Table 25:Modbus memory map: programming variables (Table 10)
Address
1138
Table 26:Modbus memory map: programming variables (Table 11)
Address
1139
Table 27:Modbus memory map: programming variables (Table 12)
Address
113B
Table 28:Modbus memory map: programming variables (Table 13)
Address
113C
113D
Table 29:Modbus memory map: programming variables (Table 14)
Address
1140
1141
Table 30:Modbus memory map: programming variables (Table 15)
Address
1142
1143
Table 31:Modbus memory map: programming variables (Table 16)
Address
1144
1145
Table 32:Modbus memory map: programming variables (Table 17)
Address
1146
1147
1148
Valid data window
0 -10 ( Value x 100)
Valid data window
0 - 100 (Value x 100)
Valid data window
1111-1999
Valid data window
0-6 (Computer SMART III 6)
0-12 (Computer SMART III 12)
0-14 (Computer SMART III 14)
Valid data window
0-999 seconds
0-999 seconds
Valid data window
0 - 100 %
0 - 100 %
Valid data window
0 ... 9999 A
0 ... 9999 A
Valid data window
0 - 80 ºC
0 - 80 ºC
Valid data window
0 (OFF), 1 (ON)
10 - 1000 mA
0 (No), 1 (Yes)
Default value
0
Default value
100
Default value
1111
Default value
6
12
14
Default value
10
50
Default value
5
8
Default value
4
5
Default value
65
70
Default value
0
300
0
67
