6.- TECHNICAL FEATURES
Rated voltage
Frequency
Consumption maximum
Installation category
Rated voltage (Un)
Voltage measurement margin
Frequency measurement margin
Input impedance
Minimum measurement voltage (Vstart)
Installation category
Nominal current (In)
Current measurement margin
Minimum measurement current (Istart)
By means of an earth leakage transformer with a ratio of 500 turns
Nominal current of the secondary
Current measurement margin
Minimum measurement current (Istart)
Voltage measurement
Current measurement
Active power measurement
Reactive power measurement
Active energy measurement
Reactive energy measurement
Quantity
Type
Maximum voltage
Maximum current
Model
Quantity
Maximum voltage, open
contacts
Maximum current
Maximum switching power
106
AC power supply
Computer SMART III 6
~
100 ... 520 V
Computer SMART III 6
10 ... 16 VA
Voltage measurement circuit
Current measurement circuit
Leakage current measurement circuit
Measurement accuracy (UNE-EN 61557-12)
Pulse outputs
Relay outputs
Computer SMART III 6
8 (6 outputs, 1 fan, 1
alarm)
Computer SMART III 12
~
100 ... 520 V
50 ... 60 Hz
Computer SMART III 12
13 ... 20 VA
CAT III 300 V
230 V , 400 V
Ph-N
20 ... 300 V , 35 ... 520 V
Ph-N
45 ... 65 Hz
660 kΩ
20 V , 35 V
Ph-N
CAT III 300 V
.../5 A or .../1 A
1 ...120 % In
50 mA
3 mA
10 mA ... 1.5 A
10 mA
0.5 % ± 1 digit
0.5 % ± 1 digit
0.5% ± 2 digits
1% ± 2 digits
Class 1
Class 2
2
NPN
24 V
50 mA
Computer SMART III 12
14 (12 outputs, 1 fan, 1
alarm)
1 kV
1 A
2500 VA
Computer SMART III
Computer SMART III 14
~
100 ... 400 V
Computer SMART III 14
14 ... 18 VA
Ph-Ph
Ph-Ph
Ph-Ph
Computer SMART III 14
16 (14 outputs, 1 fan, 1
alarm)
