Press the
38
Cosine
φ
key to switch to the Energy III consumed screen.
Power Factor
Power III
Parameters
L1 Cos
φ
L2 Cos
φ
L3 Cos
φ
Cos
φ III
L: Inductive / C: capacitive
+: Consumed / -: generated
Display the minimum values.
Display the maximum values.
Parameters
Power Factor
L1
Power Factor
L2
Power Factor
L3
Power Factor
III
L: Inductive / C: capacitive
+: Consumed / -: generated
Display the minimum values.
Display the maximum values.
Parameters
Active Power III (kW or MW)
Inductive Reactive Power III (kvarL or MvarL)
Capacitive Reactive Power III (kvarC or MvarC)
Apparent Power III (kVA or MVA)
Display the minimum values.
Display the maximum values.
