The value to be programmed in this alarm corresponds directly to the value of the total harmonic
current to be considered as the setpoint. For example: If you want to program a
when exceeding a harmonic current of 200 A measured by the regulator, program 00200 directly in
this section.
The parameters to be configured are:
Lo
value: when the device exceeds this value for 30 minutes, alarm
 The
E11
and if alarm
and activates alarm
HI
 The value: if the device exceeds this value for 30 seconds, alarm
E12
is enabled, the Computer SMART III device enters the Disconnection status and
if alarm
activates alarm
If the device falls back under the
to the normal operating status.
In the No Connection status, the device does not connect the stages, but also does not disconnect
them if the operation requires it.
In the Disconnection status, it disconnects all the stages and does not allow them to connect.
The key increases the digit value.
The key reduces the digit value.
The key skips to the previous digit and the
Press to validate the data; the
Lo HI
Value and Value:
Maximum value: 9999.
Minimum value: 1
If the value entered is lower than the minimum value or higher than the maximum value, the backlight
of the display flashes and the value entered is replaced with the minimum or maximum value, or with
the last value validated.
Press the key to access the next programming step.
If no keys are pressed for 5 minutes, the device switches to the simulation screen,
.
SCREEN"
