4�3�- KEYBOARD FUNCTIONS
The Computer SMART III has 5 keys that can be used to browse between the various screens and
program the device.
Keys functions on the measurement screens (
Note: See
Keys functions on the Configuration and Test screens, query mode (
Key
Note: See
30
Table 7: Keys functions on the measurement screens�
Key
Previous screen
Next screen
View minimum value
View maximum value
Next parameter
Very long keystroke (10 s�)
Enter the Test screens
"4.6.1. MEASUREMENT STATUS"
Table 8: Keys functions on the Configuration and Test screens, query mode�
Short keystroke
Previous screen
Next screen
Previous parameter
Next parameter
Configuration: Edit mode
Test: Start AutoTest
Very long keystroke (10 s�)
Exit the Test screens
and
"4.6.2. TEST STATUS"
):
Table 7
Short keystroke
for further details.
Test: Manual connection of the selected capacitor
Test: Manual disconnection of the selected capac-
itor
Test: Cancel the AutoTest process
for further details.
"5.- CONFIGURATION"
Long keystroke (3 s)
-
-
Delete minimum values
Delete maximum values
Enter the programming menu
):
Table 8
Long keystroke (3 s)
