When a parameter is displayed, its value and units (abbreviat-
ed) will be displayed on the right of the screen. You can
change the value of the parameter by using the Data Inc/Dec
Key. Alternately, you can press the right arrow Menu
Navigation Key once more and enter the detail screen (see
section 3.1 Menu Structure for more details). A bar graph
appears as well as min and max data points. Change the para-
meter value by pressing the Data Inc/Dec Key (the bar graph
shows the relative value of the parameter)
1311 automatically sends the change to the unit. The new
value is set as soon as the Data Inc/Dec Key is released.
Test the system at any time, even with the unit active.
To close a Menu, Sub-Menu or detail screen, press the left
arrow on the Navigation Key.

3.5 Real-time monitoring

To aid installation, service and troubleshooting, the 1311
Handheld Programmer can request and display a variety of
real-time data from the Curtis unit. Each Curtis product has
its own list of items that can be displayed. This list is found
under the Main Menu heading
'Monitor'
Use the right arrow on the Menu Navigation Key to select the
list of monitor variables. If the list is more than one screen
long, use the Up and Down Buttons arrows on the Menu
Navigation Key to scroll through the list.
In the "list" mode, every value is periodically updated.
To view a single monitor variable at a faster rate, select a sin-
gle variable from the list (using the right arrow) and a detail
screen will display. This screen will show only that variable
and the update rate will be faster.
To leave the Monitor Menu or detail screen, press the left
arrow on the Navigation Key.
page 9
Curtis 1311 Manual
