4a — MONITOR MENU
70
1 1 J U LY 2 0 0 8 D R A F T
DISPLAY
VARIABLE RANGE
Motor Temp Cutback
0–100 %
MotorTempCutback 0–4096
Controller Temp Cutback 0–100 %
ControllerTempCutback 0–4096
Undervoltage Cutback
0–100 %
UndervoltageCutback 0–4096
Overvoltage Cutback 0–100 %
OvervoltageCutback 0–4096
Monitor Menu: MOTOR TUNING
DISPLAY
VARIABLE RANGE
Base Speed Captured 0–8000 rpm
Base_Speed_Captured 0–8000
Monitor Menu: CUTBACKS
DESCRIPTION
Displays the current available as a result of
the motor temperature cutback function.
A value of 100% indicates no cutback in
current.
Displays the current available as a result
the controller temperature cutback function.
A value of 100% indicates no cutback in
current.
Displays the current available as a result
the undervoltage cutback function.
A value of 100% indicates no cutback in
current.
Displays the current available as a result
the overvoltage cutback function.
A value of 100% indicates no cutback in
current.
DESCRIPTION
Displays the value of the motor base speed
captured in the most recent acceleration.
This value is used to set the Base
Speed parameter (Program
»
Tuning Field Weakening Control menu),
using the Base Speed set procedure
described on page 62.
Curtis 1234/36/38 Manual,
»
Motor Control
Rev. D
