TUG MZ Operation Maintenance & Parts Manual page 143

Fig & Tug Part
Ind Number
1-26 3/8
1-27 ¼-20 x 1
1-28 ¼
1-29 ¼
1-30 MZ-10006
1-31 MX4-10152
1-32 MX4-10153
1-33 MX4-10157
1-34 5/16-18
1-35 MX4-10113
1-36 MD-CB1-127
1-37 MX4-10180
1-38 3/8-16 x 1 ¾
1-39 3/8
1-40 3/8-16
1-41 MX4-10202
1-42 T-S1
617501-03
1-43 TY-57
1-44 MX4-10312
MX4-10192
1-45 440E-98011
1-46 MJ-ND-4006
1-47 MX4-10055
1-48 T6-9011-149
1-49 M3-1-1048
CD373
MZ Tow Tractor
Table 2-1. Body Components (Cont'd)
Description
Washer, Flat 3/8" ID
Bolt, Hex Head Ø ¼-20 x 1¼" Long
Washer, Flat ¼" ID
Washer, Lock ¼" ID
Closeout, Drive Motor
Panel, L/H Control, Closeout
Hinge, Control Closeout
Bolt, Shoulder
Nut, Flange Lock Hex 5/16-18
Cover, Conduit Channel
Bushing
Gasket, Neoprene - Side Compartment, 6' Long
Bolt, Hex Head Ø 3/8-16 x 1¾" Long - Opt.
Washer, Flat, 3/8" ID - Opt.
Nut, Top Lock Hex 3/8-16 - Opt.
Bumper, Front Rubber "M" Style - Opt.
Decal, Maximum Towing Speed 15 MPH
Decal, Towing Speed 15 MPH
Decal, Tow with Arrow
Cover Plate, 1/8"
Connector, Duct Heater, thru Frame - Opt.
Decal, TUG
Ring, Lashing, 5/8 x 4.25 x 4.25"
Guard, Hip - Right Side
Plate, Data - Draw Bar
Decal, Electric
Chapter 4
Section 2
Qty Effective
8 1 & Up
4 "
4 "
4 "
1 "
1 "
2 "
4 "
4 "
1 "
4 "
2 "
5 As Req'd
10 "
5 "
1 "
1 Up to 80
1 81& Up
3 1 & Up
1
1 & Up
1 As Req'd
1 1 & Up
3 "
1 "
1 "
1
"
4-2-5
Rev 3
