TUG MZ Operation Maintenance & Parts Manual page 237

Tug Part Number
5/16-18 x ¾
———
¼-20 x 1
#10-16
10-16 x ¾
10-16 x ¾
3/8-16 x 1
10-24 x ½
10-24 x ½
TM1-ND-8075K
———
———
660-2-3290
BLE-0006
MX4-10182
MT-2-2024
MX4-10261
———
MZ-10083
———
MX4-10344
———
TM1-1-6537
TM1-1-6537
TM1-2-8087
M3-1-8138
MZ-10096
MZ-10096
M3-2-1051
MZ-10041
MX4-10251
MX4-10251
T6-9003-153
MZ-10113
CMA-504
CMA-504
MZ-10029
CD373
MZ Tow Tractor
Description
Screw, Bulk Head Ø 5/16-18 x ¾" Long
Screw, Fastening
Screw, Hex Head Machine Ø ¼-20 x 1" Long
Screw, Hex Washer Head - Self-Drilling
Screw, Pan Head, Self-Tapping Ø 10-16 x ¾" Long
Screw, Pan Head, Self-Tapping Ø 10-16 x ¾" Long
Screw, Phillips Head Ø 3/8-16 x 1" Long
Screw, Slotted Machine Hex Ø 10-24 x ½" Long
Screw, Slotted Machine Hex Ø 10-24 x ½" Long
Seal Kit, Front Calipers
Seal, Grease - Bottom
Seal, Grease - Top
Seat, Sears, Vinyl Coldform with Logo
Sensor, Temperature
Shackle, Front Suspension
Shaft, Pivot, 1¼" (Kit)
Shield, Splash - Harness (Weldment)
Sleeve, Retainer Bolt (Note 1)
Software, Curtis Programming (Service Item)
Spacer, Bottom King Pin
Spacer, Rear Axle
Spacer, Top King Pin
Spring, Clip - Dual Wiper
Spring, Clip - Dual Wiper
Spring, Leaf - Heavy Duty
Spring, Rear
Spring, Throttle
Spring, Throttle
Stand, Flashing Light - Opt.
Stiffener, MZ Frame - Opt.
Strain Relief, 4/0
Strain Relief, 4/0 - Opt.
Strip, Foam, Rear, 8 ft.
Strip, Rub, Mid Section - Opt.
Strip, Seal - Door, 16.5' Long
Strip, Seal - Door, 16.5' Long
Switch Assembly, Limit
Chapter 4
Section 4
Fig & Ind#
1-11
20-4b
17-10
20-17
5-15
6-15
4-9
5-11
6-11
32-4
24-6
24-3
8-6
15-8
22-7
20-13
25-24
32-9
13-
24-17
25-14
24-2
20-11
20-4e
22-6
25-12
27-10
29-17
18-10
2-19
25-26
25-26
3-3
2-20
5-2
6-2
27-12
4-4-13
Rev 3
