TUG MZ Operation Maintenance & Parts Manual page 159

Fig & Tug Part
Ind Number
8-1 3/8
8-2 3/8-16 x 1¼
8-3 3/8-16
8-4 3/8
8-5 T6-9011-103
8-6 660-2-3290
8-7 TM1-1-9590
8-8 660-2-3290-1
8-9 5/16-18
8-10 MZ-10048
8-11 BLE-ND-1075
CD373
MZ Tow Tractor
Table 2-8. Seat Assembly
Description
Washer, Flat 3/8" ID
Bolt, Hex Head Ø 3/8-16 x 1¼" Long
Nut, Top Lock Hex 3/8-16
Washer, Flat 3/8" ID
Belt, Seat (Retractable)
Seat, Sears, Vinyl Coldform with Logo
Bracket, Seat Belt
Switch, Seat, Twist Lock, 2 Pin
Nut, Flange Lock Hex 5/16-18
Closeout, Cab Harness - Opt.
Grommet, Rubber 7/8 x 1¼ x ¼
Chapter 4
Section 2
Qty Effective
8 1 & Up
8 "
8 "
12 "
2 "
2 "
4 "
1 "
8 1 & Up
1 As Req'd
1 1 & Up
4-2-21
Rev 3
