TUG MZ Operation Maintenance & Parts Manual page 199

Fig & Tug Part
Ind Number
28-1 MZ-10012
28-2 MZ-10047
28-3 MZ-10023
28-4 660-1-1913
28-5 T6-500-123
28-6 3/32 x 7/8
28-7 MZ-10002
28-8 MZ-10040
28-9 MZ-10020
28-10 MZ10021
28-11 TPG-76009-S36
28-12 MZ-10025
28-13 ½-20
28-14 ½
28-15 MZ-10011
28-16 MZ-10024
28-17 MZ-10079
28-18 MZ-10022
28-19 ½-20 x 2
CD373
MZ Tow Tractor
Table 2-28. Park Brake Cable Assembly
Description
Cable, Park Brake Primary
Anchor, Park Brake Cable
Arm, Park Brake
Yoke, End - Adjustable
Pin, Park Brake
Pin, Cotter Ø 3/32 x 7/8" Long
Axle/Motor Assembly, Rear
Clevis, Park Brake Arm
Cable, Park Brake Secondary
Eye, Terminal
Pin, Clevis, 5/16 x 1.00
Mount, Park Brake Axle
Nut, Top Lock Hex ½-20
Washer, Flat ½" ID
Clevis, with ¼ Throat for ¼-28
Plate, Pivot
Pin, Clevis, Small
Mount, Park Brake
Bolt, Hex Head Ø ½-20 x 2" Long
Chapter 4
Section 2
Qty Effective
1 1 & Up
1 "
1 "
1 "
1 "
1 "
1 "
2 "
2 "
2 "
2 "
1 "
1 "
2 "
2 "
1 "
1 "
1 "
1 "
4-2-61
Rev 3
