TUG MZ Operation Maintenance & Parts Manual page 272

PMS701 HS-TR
STD version
Tab. B
Part N° Ref. N° Designation
Teil-Nr Bestell-Nr Bezeichnung
Posiz. Codice Descrizione
4 065.0011 Axle shaft / Welle / Semiasse ponte
[4.5 kg]
7 260.0040 Left casing / Linke Büchse / Corpo sinistro
[39,5 kg]
8 260.0047 Right casing / Rechte Büchse / Corpo destro
[39,5 kg]
11 320.0032 Tone wheel / Lautrad / Ruota fonica
[0,88 kg]
15 330.0086 Differential spacer / Differential Distanzstück /
Distanziale differenziale [0,04 kg]
20 615.0006 Lever / Hebel / Leva freno positivo
[0,3 kg]
23 740.0030 Piston / Kolbe / Pistone positivo
[0,3 kg]
26 780.0009 Bleeding valve cap / Ventilpfropfen / Cappuccio spurgo freni 2
27 780.0010 Protection / Schutz / Protezione bocca raffredd.
[0,01 kg]
28 796.0003 Connection / Anschluss / Raccordo freno
[0,03 kg] ORFS 9/16-18 UNF-2A
29 800.0011 Ad just. Shim / Distanzstück / Rasamento
[0,03 kg]
34 980.0006 Bleeding valve / Ventil /Valvola spurgo freni
[0,01 kg]
35 990.0016 Socket head cap screw / Schraube /Vite TCEI
[0,05 kg] M10x70 12.9
36 ACC.0025 Speed sensor / Geschwindigkeitsensor / Sensore per motore
37 ACC.0019 Ear-ring / Ohrring/ Boccola Metaxentric
10-02764-01 70sh
41 AE0.0027 Retaining ring / Sicherungsring / Seeger per albero
UNI7435 D.50
Lista ricambi: differenziale / ruota fonica
Spare parts list: differential gear / tone wheel
Lista ricambi
Spare parts
Q.ty Spare part KIT
M.ge
Q.tà KIT ricambi
1 ►K7S.0527.0
1 ►K7S.0524.0
1 ►K7S.0525.0
1 ►K7S.0527.0
1 ►K7S.0524.0
►K7S.0524.0
2
►K7S.0525.0
2 ►K7S.0524.0
►K7S.0525.0
1 ►K7S.0525.0
2 ►K7S.0524.0
►K7S.0525.0
1 ►K7S.0527.0
2 ►K7S.0524.0
►K7S.0525.0
2 ►K7S.0524.0
►K7S.0525.0
►K7S.0525.0
1
1
1 ►K7S.0527.0
Pag. 26
