Fig . 12: Regen Current Limiting Map - TUG MZ Operation Maintenance & Parts Manual

PARAMETER
Nominal
PL_Regen_Nominal
Plus Delta
PL_Regen_Nominal_Plus_Delta
Plus 2xDelta
Nominal
PL_Regen_ _Plus_2xDelta
Plus 4xDelta
Nominal
PL_Regen_ _Plus_4xDelta
Plus 8xDelta
Nominal
PL_Regen_ _Plus_8xDelta
Fig. 12 Regen
current limiting map
(two examples).
Curtis 1234/36/38 Manual,
1 1 J U LY 2 0 0 8 D R A F T
3 — PROGRAMMABLE PARAMETERS:
REGEN LIMITING MAP MENU
ALLOWABLE
RANGE
0–100 % Sets
0–32767
0–100 % Sets
These parameters define the percentage of regen current limit
0–32767
that will be applied at the speeds defined by the base speed
and delta speed parameters.
0–100 % Sets
0–32767
various speeds. One possible use is to compensate for the
torque-speed characteristic of the motor.
0–100 % Sets
0–32767
0–100 % Sets
0–32767
Rev. D
DESCRIPTION
The curve can be shaped to limit the available torque at
Regen Limiting Map Parameters
41
