TUG MZ Operation Maintenance & Parts Manual page 235

Tug Part Number
T6-3001-60028
¼-20
½-13
½-20
½-20
10-32
3/8-16
3/8-16
3/8-16
5/16-18
5/8-11
———
TM1-ND-8076
MZ-10019
MZ-10019
MZ-10008-10
MZ-10008-10
MX4-10152
MX4-10151
BLE-0002-1
MZ-10052
MX4-10056
M3-1-8168
TM1-ND-8077B
TPG-76009-S36
MZ-10079
1/8 x 1½
3/8 x 2
3/32 - 1½
3/32 x 7/8
3/32 x 7/8
3/32 x 7/8
———
MZ-10005
T6-500-123
T6-500-123
T6-500-123
CD373
MZ Tow Tractor
Description
Nut, Spindle
Nut, Top Lock Hex ¼-20
Nut, Top Lock Hex ½-13
Nut, Top Lock Hex ½-20
Nut, Top Lock Hex ½-20
Nut, Top Lock Hex 10-32
Nut, Top Lock Hex 3/8-16
Nut, Top Lock Hex 3/8-16
Nut, Top Lock Hex 3/8-16 - Opt.
Nut, Top Lock Hex 5/16 -18
Nut, Top Lock Hex 5/8-11
O-Ring (Note 1)
Pad Set, Brake Caliper (Semi-Metallic)
Panel, Access Console
Panel, Console Access
Panel, Controller Mount
Panel, Controller Mount
Panel, L/H Control, Closeout
Panel, R/H Control, Closeout
Panel, Receptacle Mount - Weldment
Panel, Roof
Pedal Assembly, Brake
Pin, Brake Pedal Pivot
Pin, Caliper Mounting
Pin, Clevis, 5/16 x 1.00
Pin, Clevis, Small
Pin, Cotter Ø 1/8 x 1½" Long
Pin, Cotter Ø 3/18 x 2" Long
Pin, Cotter Ø 3/32 x 1½" Long
Pin, Cotter Ø 3/32 x 7/8" Long
Pin, Cotter Ø 3/32 x 7/8" Long
Pin, Cotter Ø 3/32 x 7/8" Long
Pin, King, KB423
Pin, Motor/Axle Pivot
Pin, Park Brake
Pin, Park Brake
Pin, Park Brake
Chapter 4
Section 4
Fig & Ind#
24-12
25-4
25-13
22-13
28-13
25-28
3-12
8-3
1-40
4-5
22-3
32-8
32-2
27-4
1-19
13-8
14-1
1-31
1-10
17-4
3-13
29-1
29-3
23-4
28-11
28-17
29-7
24-13
10-5
27-7
28-6
29-6
24-7
25-2
27-8
28-5
29-5
4-4-11
Rev 3
