TUG MZ Operation Maintenance & Parts Manual page 273

PMS701 HS-TR
STD version
Tab. B
Part N° Ref. N° Designation
Teil-Nr Bestell-Nr Bezeichnung
Posiz. Codice Descrizione
42 AE0.0029 Retaining ring / Sicherungsring / Seeger per albero
UNI7435 D.30
47 AT1.0048 Seal ring / Siegelring/ Anello tenuta
TIPO AS 40x68x8 VITON
48 AT4.0009 Shaft seal / Wellendichtring / Anello tenuta
A 30x40x7 VITON
49 AT4.0010 Shaft seal / Wellendichtring / Anello tenuta
A 50x80x8 DIN 3760 VITON
50 AT5.0058 O-ring / O-ring / O-ring
OR3925 Di=234.62x2.62
51 AT5.0114 O-ring / O-ring / O-ring
OR2118 29.87x1.78
52 AT9.0035 V-ring / V-ring / V-ring
cr400251 VR2 24-27
60 DIF.0002 Differential gear / Differentialgetriebe/ Differenziale
62 GRA.0002 Grub screw / Dübel / Grano testa piana
M6x10 UNI5923
69 MOT.0031 Motor / Motor / Motore asincrono
71 RO1.0014 Kasher / Scheibe / Rondella rame
(M14)
79 TAP.0046 Breather plug / Sicherheitsventil / Tappo sfiato
M14x1.5 (TSF 1M)
81 VC1.0002 Socket head cap screw / Schraube / Vite TCEI
M12x40 8.8 nera
83 VC1.0053 Socket head cap screw / Schraube /Vite TCEI
M6x14 - 8.8 nera
85 VC1.0078 Socket head cap screw / Schraube / Vite TCEI
M12x70 8.8 nera UNI 5931
86 VC1.0085 Socket head cap screw / Schraube / Vite TCEI
M8x40 12.9 nera
Lista ricambi: differenziale / ruota fonica
Spare parts list: differential gear / tone wheel
Lista ricambi
Spare parts
Q.ty Spare part KIT
M.ge
Q.tà KIT ricambi
1 ►K7S.0527.0
1 ►K7S.0307.0
1 ►K7S.0307.0
1 ►K7S.0307.0
►KIT.7013.0
1 ►K7S.0307.0
1 ►K7S.0307.0
1 ►KIT.7013.0
►K7S.0307.0
1 ►K7S.0527.0
1 ►K7S.0527.0
1 ►K7S.0527.0
2 ►K7S.0524.0
►K7S.0525.0
2 ►K7S.0524.0
►K7S.0525.0
4 ►K7S.0111.0
3 ►K7S.0525.0
22 ►K7S.0111.0
6 ►K7S.0111.0
Pag. 27
