6.1.5
USB
The conga-TS175 offers eight USB 2.0 interfaces on the A–B connector and four SuperSpeed signals on the C–D connector. The xHCI host
controller supports:
• USB 3.0 specification
• SuperSpeed, High-Speed, Full-Speed and Low-Speed USB signaling
• data transfers of up to 5 Gb/s
• supports USB debug port on all USB 3.0 capable ports
Note
The xHCI controller supports USB debug port on all USB 3.0 capable ports.
6.1.6
Gigabit Ethernet
The conga-TS175 offers a Gigabit Ethernet interface via an onboard Intel
10/100/1000 Mb/s and half-duplex operation at 10/100 Mb/s.
Note
1. The GBE0_LINK# output is not active during a 10 Mb connection. It is only active during a 100 Mb or 1 Gb connection. This is a limitation
of Ethernet Phy since it has only three LED outputs—ACT#, LINK100# and LINK1000#.
2. The GBE0_LINK# signal is a logic AND of the GBE0_LINK100# and GBE0_LINK1000# signals on the conga-TS175 module.
6.1.7
High Definition Audio (HDA) Interface
The conga-TS175 provides an interface that supports the connection of HDA audio codecs.
6.1.8
LPC Bus
The conga-TS175 offers the LPC (Low Pin Count) bus through the Intel
10.1.1.
Copyright © 2017 congatec AG
i219-LM Phy. The interface supports full-duplex operation at
®
PCH-LP. For information about the decoded LPC addresses, see section
®
TSKLm16
30/71
