Pin Row A Pin
A37 USB6+ B37
A38 USB_6_7_OC# B38
A39 USB4- B39
A40 USB4+ B40
A41 GND (FIXED) B41
A42 USB2- B42
A43 USB2+ B43
A44 USB_2_3_OC# B44
A45 USB0- B45
A46 USB0+ B46
A47 VCC_RTC B47
A48 EXCD0_PERST# B48
A49 EXCD0_CPPE# B49
A50 LPC_SERIRQ B50
A51 GND (FIXED) B51
A52 PCIE_TX5+ B52
A53 PCIE_TX5- B53
A54 GPI0 B54
A55 PCIE_TX4+ B55
Note
The signals marked with asterisk symbol (*) are not connected on the conga-TS175.
Copyright © 2017 congatec AG
Row B Pin Row A
USB7+ A92 SPI_MISO
USB_4_5_OC# A93 GPO0
USB5- A94 SPI_CLK
USB5+ A95 SPI_MOSI
GND (FIXED) A96 TPM_PP
USB3- A97 TYPE10# (*)
USB3+ A98 SER0_TX
USB_0_1_OC# A99 SER0_RX
USB1- A100 GND (FIXED)
USB1+ A101 SER1_TX
EXCD1_PERST# A102 SER1_RX
EXCD1_CPPE# A103 LID#
SYS_RESET# A104 VCC_12V
CB_RESET# A105 VCC_12V
GND (FIXED) A106 VCC_12V
PCIE_RX5+ A107 VCC_12V
PCIE_RX5- A108 VCC_12V
GPO1 A109 VCC_12V
PCIE_RX4+ A110 GND (FIXED)
Pin Row B
B92 VGA_BLU
B93 VGA_HSYNC
B94 VGA_VSYNC
B95 VGA_I2C_CK
B96 VGA_I2C_DAT
B97 SPI_CS#
B98 RSVD
B99 RSVD
B100 GND (FIXED)
B101 FAN_PWMOUT
B102 FAN_TACHIN
B103 SLEEP#
B104 VCC_12V
B105 VCC_12V
B106 VCC_12V
B107 VCC_12V
B108 VCC_12V
B109 VCC_12V
B110 GND (FIXED)
