Bottom-Side (Optional DRAM Sensor):

The conga-TS175 offers an optional sensor on the bottom side of the module. This sensor measures the temperature of the DRAM module and

is defined in CGOS API as CGOS_TEMP_BOTDIMM_ENV.

The DRAM sensor location is shown below:

Optional DRAM Sensor Location

(BOM option)

Note

The optional DRAM sensors are not populated on conga-TS175 standard variants. The sensors are only available as assembly option.
