Table 15 DDI Signal Description

Signal Pin # Description
DDI1_PAIR0+ D26 Multiplexed with DP1_LANE0+ and TMDS1_DATA2+.
DDI1_PAIR0- D27 Multiplexed with DP1_LANE0- and TMDS1_DATA2-.
DDI1_PAIR1+ D29 Multiplexed with DP1_LANE1+ and TMDS1_DATA1+.
DDI1_PAIR1- D30 Multiplexed with DP1_LANE1- and TMDS1_DATA1-.
DDI1_PAIR2+ D32 Multiplexed with DP1_LANE2+ and TMDS1_DATA0+.
DDI1_PAIR2- D33 Multiplexed with DP1_LANE2- and TMDS1_DATA0-.
DDI1_PAIR3+ D36 Multiplexed with DP1_LANE3+ and TMDS1_CLK+.
DDI1_PAIR3- D37 Multiplexed with DP1_LANE3- and TMDS1_CLK-.
DDI1_PAIR4+ C25 Multiplexed with SDVO1_INT+.
DDI1_PAIR4- C26 Multiplexed with SDVO1_INT-.
DDI1_PAIR5+ C29 Multiplexed with SDVO1_TVCLKIN+.
DDI1_PAIR5- C30 Multiplexed with SDVO1_TVCLKIN-.
DDI1_PAIR6+ C15 Multiplexed with SDVO1_FLDSTALL+.
DDI1_PAIR6- C16 Multiplexed with SDVO1_FLDSTALL-.
DDI1_HPD C24 Multiplexed with DP1_HPD and HDMI1_HPD.
DDI1_CTRLCLK_AUX+ D15 Multiplexed with DP1_AUX+ and HMDI1_CTRLCLK.
DP AUX+ function if DDI1_DDC_AUX_SEL is no connect.
HDMI/DVI I2C CTRLCLK if DDI1_DDC_AUX_SEL is pulled high
DDI1_CTRLDATA_AUX- D16 Multiplexed with DP1_AUX- and HDMI1_CTRLDATA.
DP AUX- function if DDI1_DDC_AUX_SEL is no connect.
HDMI/DVI I2C CTRLDATA if DDI1_DDC_AUX_SEL is pulled high
DDI1_DDC_AUX_SEL D34 Selects the function of DDI1_CTRLCLK_AUX+ and DDI1_CTRLDATA_AUX-.
This pin shall have a IM pull-down to logic ground on the module. If this
input is floating, the AUX pair is used for the DP AUX+/- signals. If pulled-
high, the AUX pair contains the CTRLCLK and CTRLDATA signals.
DDI2_PAIR0+ D39 Multiplexed with DP2_LANE0+ and TMDS2_DATA2+.
DDI2_PAIR0- D40 Multiplexed with DP2_LANE0- and TMDS2_DATA2-.
DDI2_PAIR1+ D42 Multiplexed with DP2_LANE1+ and TMDS2_DATA1+.
DDI2_PAIR1- D43 Multiplexed with DP2_LANE1- and TMDS2_DATA1-.
DDI2_PAIR2+ D46 Multiplexed with DP2_LANE2+ and TMDS2_DATA0+.
DDI2_PAIR2- D47 Multiplexed with DP2_LANE2- and TMDS2_DATA0-.
DDI2_PAIR3+ D49 Multiplexed with DP2_LANE3+ and TMDS2_CLK+.
DDI2_PAIR3- D50 Multiplexed with DP2_LANE3- and TMDS2_CLK-.
DDI2_HPD D44 Multiplexed with DP2_HPD and HDMI2_HPD.
DDI2_CTRLCLK_AUX+ C32 Multiplexed with DP2_AUX+ and HDMI2_CTRLCLK.
DP AUX+ function if DDI2_DDC_AUX_SEL is no connect.
HDMI/DVI I2C CTRLCLK if DDI2_DDC_AUX_SEL is pulled high
DDI2_CTRLDATA_AUX- C33 Multiplexed with DP2_AUX- and HDMI2_CTRLDATA.
DP AUX- function if DDI2_DDC_AUX_SEL is no connect.
HDMI/DVI I2C CTRLDATA if DDI2_DDC_AUX_SEL is pulled high.
Copyright © 2017 congatec AG
I/O PU/PD
O PCIE
O PCIE
O PCIE
O PCIE
I 3.3V PD 1M
PD100k
I/O PCIE
I/O OD 3.3V
PU 100k 3.3V Boot strap signal (see note below).
I/O PCIE
I/O OD 3.3V
I 3.3V PD 1M
O PCIE
O PCIE
O PCIE
O PCIE
I 3.3V PD 1M
PD 100k
I/O PCIE
I/O OD 3.3V
PU 100k 3.3V Boot strap signal (see note below).
I/O PCIE
I/O OD 3.3V
TSKLm16
Comment
Not supported
Not supported
Not supported
Enable strap is already populated.
Enable strap is already populated.
52/71
