Table 21 Serial ATA Signal Descriptions

Signal Pin # Description
SATA0_RX+ A19 Serial ATA channel 0, Receive Input differential pair.
SATA0_RX- A20
SATA0_TX+ A16 Serial ATA channel 0, Transmit Output differential pair.
SATA0_TX- A17
SATA1_RX+ B19 Serial ATA channel 1, Receive Input differential pair.
SATA1_RX- B20
SATA1_TX+ B16 Serial ATA channel 1, Transmit Output differential pair.
SATA1_TX- B17
SATA2_RX+ A25 Serial ATA channel 2, Receive Input differential pair.
SATA2_RX- A26
SATA2_TX+ A22 Serial ATA channel 2, Transmit Output differential pair.
SATA2_TX- A23
SATA3_RX+ B25 Serial ATA channel 3, Receive Input differential pair.
SATA3_RX- B26
SATA3_TX+ B22 Serial ATA channel 3, Transmit Output differential pair.
SATA3_TX- B23
(S)ATA_ACT# A28 ATA (parallel and serial) or SAS activity indicator, active low.

Table 22 USB 2.0 Signal Descriptions

Signal Pin # Description
USB0+ A46 USB Port 0, data + or D+
USB0- A45 USB Port 0, data - or D-
USB1+ B46 USB Port 1, data + or D+
USB1- B45 USB Port 1, data - or D-
USB2+ A43 USB Port 2, data + or D+
USB2- A42 USB Port 2, data - or D-
USB3+ B43 USB Port 3, data + or D+
USB3- B42 USB Port 3, data - or D-
USB4+ A40 USB Port 4, data + or D+
USB4- A39 USB Port 4, data - or D-
USB5+ B40 USB Port 5, data + or D+
USB5- B39 USB Port 5, data - or D-
USB6+ A37 USB Port 6, data + or D+
USB6- A36 USB Port 6, data - or D-
USB7+ B37 USB Port 7, data + or D+
USB7- B36 USB Port 7, data - or D-
Copyright © 2017 congatec AG
I/O PU/PD Comment
I SATA Supports Serial ATA specification, Revision 3.0
O SATA Supports Serial ATA specification, Revision 3.0
I SATA Supports Serial ATA specification, Revision 3.0
O SATA Supports Serial ATA specification, Revision 3.0
I SATA Supports Serial ATA specification, Revision 3.0
O SATA Supports Serial ATA specification, Revision 3.0
I SATA Supports Serial ATA specification, Revision 3.0
O SATA Supports Serial ATA specification, Revision 3.0
I/O 3.3v
I/O PU/PD Comment
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
I/O USB 2.0 compliant. Backwards compatible to USB 1.1
