7.1.5

Power Loss Control

The cBC has full control of the power-up of the module and therefore can be used to specify the behavior of the system after an AC power loss
condition. Supported modes are "Always On", "Remain Off" and "Last State".
7.1.6

Fan Control

The conga-TS175 has additional signals and functions to further improve system management. One of these signals is an output signal called
FAN_PWMOUT that allows system fan control using a PWM (Pulse Width Modulation) output. Additionally, there is an input signal called
FAN_TACHOIN that provides the ability to monitor the system's fan RPMs (revolutions per minute). This signal must receive two pulses per
revolution in order to produce an accurate reading. For this reason, a two pulse per revolution fan or similar hardware solution is recommended.
Note
1. A four wire fan must be used to generate the correct speed readout.
2. For the correct fan control (FAN_PWMOUT, FAN_TACHIN) implementation, see the COM Express Design Guide.
7.2

OEM BIOS Customization

The conga-TS175 is equipped with congatec Embedded BIOS, which is based on American Megatrends Inc. Aptio UEFI firmware. The
congatec Embedded BIOS allows system designers to modify the BIOS. For more information about customizing the congatec Embedded
BIOS, refer to the congatec System Utility user's guide CGUTLm1x.pdf on the congatec website at www.congatec.com or contact technical
support.
The customization features supported are described below:
7.2.1

OEM Default Settings

This feature allows system designers to create and store their own BIOS default configuration. Customized BIOS development by congatec for
OEM default settings is no longer necessary because customers can easily perform this configuration by themselves using the congatec system
utility CGUTIL. See congatec application note AN8_Create_OEM_Default_Map.pdf on the congatec website for details on how to add OEM
default settings to the congatec Embedded BIOS.
