Lvds/Edp; Vga; Sata - Congatec COM Express conga-TS175 User Manual

7th generation intel core i7, i5, i3 and xeon processor with either qm175, hm175, or cm238 chipset

Table of Contents

6.1.3.2

LVDS/eDP

The conga-TS175 offers an LVDS interface. The interface supports the following:

• optional eDP overlay on the A–B connector via a hardware change (assembly option)

• single or dual channel LVDS (color depths of 18 bpp or 24 bpp)

• integrated flat panel interface with clock frequency up to 112 MHz

• VESA and OpenLDI LVDS color mappings

• automatic panel detection via Embedded Panel Interface based on VESA EDID

• resolution up to 1920x1200 in dual LVDS bus mode

Note

The LVDS/eDP interface supports either LVDS or eDP signals. Both interfaces are not supported simultaneously.

6.1.3.3

The conga-TS175 offers a VGA interface via an eDP to VGA converter, connected to the two upper data lanes of the embedded DisplayPort.

Note

To enable VGA interface, set the Digital Display Interface 3 to HDMI/DVI from the BIOS menu.

6.1.4

The conga-TS175 offers four SATA interfaces (SATA 0-3) on the A–B connector. The interfaces support:

• independent DMA operation

• data transfer rates up to 6.0 Gb/s

• AHCI mode using memory space and RAID mode

• Hot-plug detect

1.3

TSKLm16

29/71
