Congatec COM Express conga-TS175 User Manual page 48

Pin Row C
C39 DDI3_PAIR0+
C40 DDI3_PAIR0-
C41 GND (FIXED)
C42 DDI3_PAIR1+
C43 DDI3_PAIR1-
C44 DDI3_HPD
C45 RSVD
C46 DDI3_PAIR2+
C47 DDI3_PAIR2-
C48 RSVD
C49 DDI3_PAIR3+
C50 DDI3_PAIR3-
C51 GND (FIXED)
C52 PEG_RX0+
C53 PEG_RX0-
C54 TYPE0#
C55 PEG_RX1+
Note
The signals marked with an asterisk symbol (*) are not supported on the conga-TS175.
Copyright © 2017 congatec AG
Pin Row D Pin
D39 DDI2_PAIR0+ C94
D40 DDI2_PAIR0- C95
D41 GND (FIXED) C96
D42 DDI2_PAIR1+ C97
D43 DDI2_PAIR1- C98
D44 DDI2_HPD C99
D45 RSVD C100
D46 DDI2_PAIR2+ C101
D47 DDI2_PAIR2- C102
D48 RSVD C103
D49 DDI2_PAIR3+ C104
D50 DDI2_PAIR3- C105
D51 GND (FIXED) C106
D52 PEG_TX0+ C107
D53 PEG_TX0- C108
D54 PEG_LANE_RV# C109
D55 PEG_TX1+ C110
Row C Pin Row D
PEG_RX13+ D94 PEG_TX13+
PEG_RX13- D95 PEG_TX13-
GND D96 GND
RVSD D97 RSVD
PEG_RX14+ D98 PEG_TX14+
PEG_RX14- D99 PEG_TX14-
GND (FIXED) D100 GND (FIXED)
PEG_RX15+ D101 PEG_TX15+
PEG_RX15- D102 PEG_TX15-
GND D103 GND
VCC_12V D104 VCC_12V
VCC_12V D105 VCC_12V
VCC_12V D106 VCC_12V
VCC_12V D107 VCC_12V
VCC_12V D108 VCC_12V
VCC_12V D109 VCC_12V
GND (FIXED) D110 GND (FIXED)
