8

conga Tech Notes

The conga-TS175 has some technological features that require additional explanation. The following section will give the reader a better
understanding of some of these features.
8.1 Intel Processor Features
®
8.1.1

Adaptive Thermal Monitor and Catastrophic Thermal Protection

Intel ® Xeon, Core™ i7/i5/i3 and Celeron
integrated TCC (Thermal Control Circuit) activates if the processor silicon reaches its maximum operating temperature. The activation
temperature that the Intel
submenu "CPU submenu".
The Adaptive Thermal Monitor controls the processor temperature using two methods:
• Adjusting the processor's operating frequency and core voltage (EIST transitions)
• Modulating (start/stop) the processor's internal clocks at a duty cycle of 25% on and 75% off
When activated, the TCC causes both processor core and graphics core to reduce frequency and voltage adaptively. The Adaptive Thermal
Monitor will remain active as long as the package temperature remains at its specified limit. Therefore, the Adaptive Thermal Monitor will
continue to reduce the package frequency and voltage until the TCC is de-activated. Clock modulation is activated if frequency and voltage
adjustments are insufficient. Additional hardware, software drivers, or operating system support is not required.
Note
1. For THERMTRIP# to switch off the system automatically, use an ATX style power supply
2. The maximum operating temperature for Intel® Xeon, Core™ i7/i5/i3 and Celeron
3. To ensure that the TCC is active for only short periods of time, thus reducing the impact on processor performance to a minimum, it is
necessary to have a properly designed thermal solution. The Intel
can provide you with more information about this subject.
Copyright © 2017 congatec AG
® processors have a thermal monitor feature that helps to control the processor temperature. The
® Thermal Monitor uses to activate the TCC can be slightly modified via TCC Activation Offset in BIOS setup
processors is 100°C
®
® Xeon, Core™ i7/i5/i3 and Celeron
TSKLm16
® processor's respective datasheet
