Signal Pin # Description
PEG_TX0+ D52 PCI Express Graphics Transmit Output differential pairs.
Note: Can also be used as PCI Express Transmit Output differential pairs 16 through 31
PEG_TX0- D53
known as PCIE_TX[16-31] + and -.
PEG_TX1+ D55
PEG_TX1- D56
PEG_TX2+ D58
PEG_TX2- D59
PEG_TX3+ D61
PEG_TX3- D62
PEG_TX4+ D65
PEG_TX4- D66
PEG_TX5+ D68
PEG_TX5- D69
PEG_TX6+ D71
PEG_TX6- D72
PEG_TX7+ D74
PEG_TX7- D75
PEG_TX8+ D78
PEG_TX8- D79
PEG_TX9+ D81
PEG_TX9- D82
PEG_TX10+ D85
PEG_TX10- D86
PEG_TX11+ D88
PEG_TX11- D89
PEG_TX12+ D91
PEG_TX12- D92
PEG_TX13+ D94
PEG_TX13- D95
PEG_TX14+ D98
PEG_TX14- D99
PEG_TX15+ D101
PEG_TX15- D102
PEG_LANE_RV# D54 PCI Express Graphics lane reversal input strap. Pull low on the carrier board to reverse lane
order.
Note
Some signals have special functionality during the reset process. They may bootstrap some basic important functions of the module. For more
information refer to section 9.2 "Boot Strap Signals".
Copyright © 2017 congatec AG
I/O
O PCIE
I
TSKLm16
PU/PD Comment
PU 10k 3.3V PEG_LAN_RV# is a boot strap
signal (see note below)
