Table 8 Maximum Supported Resolutions

Interface Max. Resolution
Option 1 DP or
TMDS
Option 2 DP or
TMDS
Option 3 DP or
TMDS
Option 4 DP or
TMDS
Note
1. If VGA interface is enabled in the BIOS menu, the third DDI interface (DDI3) will support only TMDS.
2. To enable VGA, go to Advanced -> Graphics menu and change the Digital Display Interface 3 option.
6.1.3.1

DisplayPort (DP)

The conga-TS175 supports the following features:
• up to three dual mode DP ports (DP++)
• VESA DisplayPort Standard versions 1.2
• up to 4096x2304 resolutions at 60 Hz
• audio formats such as linear PCM, Dolby Digital (AC-3), Dolby TrueHD, DTS, DTS-HD Master Audio and up to 8 channels
• up to three independent DP displays
Note
A maximum of two independent DP displays are supported if the VGA interface is enabled.
Copyright © 2017 congatec AG
Display 1
Interface
4096x2304 @ 60Hz, 24 bpp/ DP or
4096x2160 @ 30Hz, 24 bpp TMDS
4096x2304 @ 60Hz, 24 bpp/ DP or
4096x2160 @ 30Hz, 24 bpp TMDS
4096x2304 @ 60Hz, 24 bpp/ DP or
4096x2160 @ 30Hz, 24 bpp TMDS
4096x2304 @ 60Hz, 24 bpp/ VGA
4096x2160 @ 30Hz, 24 bpp
Display 2
Max. Resolution Interface
4096x2304 @ 60Hz, 24 bpp/ DP or
4096x2160 @ 30Hz, 24 bpp TMDS
4096x2304 @ 60Hz, 24 bpp/ LVDS or
4096x2160 @ 30Hz, 24 bpp eDP (BOM Option)
4096x2304 @ 60Hz, 24 bpp/ VGA
4096x2160 @ 30Hz, 24 bpp
1920x1200 @ 60Hz LVDS or
eDP (BOM Option)
TSKLm16
Display 3
Max. Resolution
4096x2304 @ 60Hz, 24 bpp/
4096x2160 @ 30Hz, 24 bpp
1920x1200 @ 60Hz (dual LVDS mode)
4096x2304 @ 60Hz, 24bpp
1920x1200 @ 60Hz
1920x1200 @ 60Hz (dual LVDS mode)
4096x2304 @ 60Hz, 24bpp
