USB Interfaces

The conga-SMX8-X offers pins for five USB ports by default. The USB[1:4] pins are provided via a TI TUSB8041 USB 3.0 hub. USB0 is directly
routed to the SoC.
Optionally, the conga-SMX8-X can be offered without the USB hub and the USB signals from the SoC directly routed to the USB3 pins instead
(assembly option).
Optionally, the conga-SMX8-X can offer an onboard Wi-Fi/BT module instead of the USB4 pins.¹ For more information, see section 6.4 "Wi-Fi
and Bluetooth".
The table below shows the default and optional USB combinations:

Table 10 USB Combination

SMARC 8QuadXPlus
8DualXPlus
USB0 2 USB 2.0 OTG
USB1 USB 2.0
USB2 USB 3.0
USB3³ USB 3.0
USB4 USB 2.0
Note
1. The conga-SMX8-X module variant PN: 051104 offers Wi-Fi/BT by default instead of USB4.
USB0 is used for the Serial Downloader mode. Fore more information, see FORCE_RECOV# description in section 5.13 "Boot Select".
2.
3. The conga-SMX8-X module variants with NXP i.MX 8DualX SoC do not support USB 3.0 because this SoC does not provide USB 3.0 signals.
5.10

PCI Express™

The conga-SMX8-X offers PCIE_A pins for one PCI Express x1 Gen3 bus with a bitrate of up to 8 GTps.
