Table 17 Displayport (Dp) Signal Descriptions - Congatec COM Express conga-TS175 User Manual

Signal Pin # Description
HDMI3_CTRLDATA C37 TMDS I
Multiplexed with DDI3_CTRLDATA_AUX-
Note
1. Some signals have special functionality during the reset process. They may bootstrap some basic important functions of the module. For
more information refer to section 9.2 "Boot Strap Signals".
2. The conga-TS175 does not natively support TMDS. A DP++ to TMDS converter (e.g PTN3360D) needs to be implemented.

Table 17 DisplayPort (DP) Signal Descriptions

Signal Pin # Description
DP1_LANE3+ D36 Uni-directional main link for the transport of isochronous streams and secondary data.
DP1_LANE3- D37 Multiplexed with DDI1_PAIR3+ and DDI1_PAIR3-.
DP1_LANE2+ D32 Uni-directional main link for the transport of isochronous streams and secondary data.
DP1_LANE2- D33 Multiplexed with DDI1_PAIR2+ and DDI1_PAIR2-.
DP1_LANE1+ D29 Uni-directional main link for the transport of isochronous streams and secondary data.
DP1_LANE1- D30 Multiplexed with DDI1_PAIR1+ and DDI1_PAIR1-.
DP1_LANE0+ D26 Uni-directional main link for the transport of isochronous streams and secondary data.
DP1_LANE0- D27 Multiplexed with DDI1_PAIR0+ and DDI1_PAIR0-.
DP1_HPD C24 Detection of Hot Plug / Unplug and notification of the link layer.
Multiplexed with DDI1_HPD.
DP1_AUX+ D15 Half-duplex bi-directional AUX channel for services such as link configuration or
maintenance and EDID access.
DP1_AUX- D16 Half-duplex bi-directional AUX channel for services such as link configuration or
maintenance and EDID access.
DP2_LANE3+ D49 Uni-directional main link for the transport of isochronous streams and secondary data.
DP2_LANE3- D50 Multiplexed with DDI2_PAIR3+ and DDI2_PAIR3-
DP2_LANE2+ D46 Uni-directional main link for the transport of isochronous streams and secondary data.
DP2_LANE2- D47 Multiplexed with DDI2_PAIR2+ and DDI2_PAIR2-
DP2_LANE1+ D42 Uni-directional main link for the transport of isochronous streams and secondary data.
DP2_LANE1- D43 Multiplexed with DDI2_PAIR1+ and DDI2_PAIR1-
DP2_LANE0+ D39 Uni-directional main link for the transport of isochronous streams and secondary data.
DP2_LANE0- D40 Multiplexed with DDI2_PAIR0+ and DDI1_PAIR0-
DP2_HPD D44 Detection of Hot Plug / Unplug and notification of the link layer.
Multiplexed with DDI2_HPD.
DP2_AUX+ C32 Half-duplex bi-directional AUX channel for services such as link configuration or
maintenance and EDID access.
Copyright © 2017 congatec AG
C Control Data
2
I/O PU/PD Comment
I/O OD 3.3V PU 100k HDMI3_CTRLDATA is a boot strap signal (see note below).
3.3V HDMI enable strap is already
I/O PU/PD Comment
O PCIE
O PCIE
O PCIE
O PCIE
I 3.3V PD 1M
I/O PCIE PD 100k
I/O PCIE PU 100k
3.3V
O PCIE
O PCIE
O PCIE
O PCIE
I 3.3V PD 1M
I/O PCIE PD 100k
TSKLm16
populated.
Boot strap signal (see note below)
Enable strap is already populated.
55/71
