3 Installation and Configuration
3.1 Configuration DIP Switches
S5U13700B00C Rev 1.0 Evaluation Board
Rev. 1.1
The S5U13700B00C evaluation board incorporates a DIP switch and 9 jumpers, which
allow configuration of the board.
An 8 position DIP switch (S1) is used to configure the S1D13700 for different Host Bus
interfaces and to select the FPSHIFT cycle time. The following figure shows the location
of DIP switch S1 on the S5U13700B00C.
Top View
Figure 3-1: Configuration DIP Switch (S1) Location
Seiko Epson Corporation
Installation and Configuration
DIP Switch - S1
