3.2 Configuration Jumpers

Jumper Function
JP1 HIOVDD
JP2 NIOVDD
JP3 COREVDD
JP4 CLKI Source
JP5 CLKI Input Disable
JP6 Crystal Enable
JP7 HIOVDD Voltage
JP8 NIOVDD Voltage
JP9 RESET Source
= Required settings when using the PC Card adapter
S5U13700B00C Rev 1.0 Evaluation Board
Rev. 1.1
The S5U13700B00C has 9 jumper blocks which allow the configuration of the board.
Table 3-2: Jumper Summary
Position 1-2
Normal
Normal
Normal
On Board Oscillator (U2)
Disable CLKI Input
(CLKI is tied to VSS)
Enable Crystal Output
+3.3V
+3.3V
Manual Reset
Seiko Epson Corporation
Installation and Configuration
Position 2-3
—
—
—
Host Interface Connector
Disable Crystal Input
(XCG1 is tied to VSS)
Disable Crystal Output
+5V
+5V
Host Interface Reset
No Jumper
HIOVDD current
measurement
NIOVDD current
measurement
COREVDD current
measurement
—
—
—
—
—
—
9
