JP3 - COREVDD
JP3 can be used to measure the current consumption of the S1D13700 core.
When the jumper is at position 1-2, normal operation is selected.
When no jumper is installed, core current consumption can be measured across JP3.
JP3
Normal Operation
COREVDD current
measurement
Top View
Figure 3-4: Configuration Jumper JP3 Location
