NetVanta 5305 Hardware Installation Guide
Reviewing the Rear Panel Design
Figure 2 on page 19
shows the NetVanta 5305 AC rear panel layout, and
NetVanta 5305 DC rear panel layout. Pinouts for the connectors are given in
1
2
3
1
2
3
Rear Panel Interfaces
CONSOLE Port
The
port, a DB-9 interface located on the rear panel, connects to a computer or modem and
C
ONSOLE
provides the following functions:
•
Accepts electrical EIA-232 input from a PC or modem for controlling the NetVanta 5305.
•
Operates at rates ranging from 9.6 kbps to 115.2 kbps.
•
Acts an input for either VT100 or PC control.
61200990L1-34N
Figure 2. NetVanta 5305 AC Rear Panel Layout
Figure 3. NetVanta 5305 DC Rear Panel Layout
Copyright © 2010 ADTRAN, Inc.
Product Overview
Figure 3 on page 19
shows the
Appendix A on page
4
CAUTION:
REMOVE POWER CORD PRIOR
TO REMOVAL OF POWER SUPPLY
5
85-130VAC/190-250VAC
4A/2A 50/60Hz
6
4
CAUTION REMOVE POWER CORD PRIOR
TO REMOVAL OF POWER SUPPLY
5
USE COPPER
CONDUCTORS ONLY
A
B
RET -48V RET -48V
6
33.
19
