Web-Based Management; 4-Port Gbic Multilayer Switching Module (Model Number 3Cb9Rg4) - 3Com 4007 Release Note

86 C 6: R I M S M
HAPTER ELEASE SSUES FOR ULTILAYER WITCHING ODULES
Web-based Using the WebConsole to renumber the 100th QoS flow classifier
Management removes that classifier when you have defined the maximum number
of flow classifiers (100 classifiers). You can renumber all other flow
classifiers through the WebConsole correctly. To renumber the 100th
flow classifier, you must delete it and redefine it. (29845)
If you define an advertisementAddress for an IP interface through the
WebConsole, you cannot modify the directedBroadcast,
icmp
Redirect, or proxyArp parameters. You can modify these
parameters through the Administration Console. (29897)
You cannot remove a control rate limit using the WebConsole Traffic
Policy Control Remove form when only one rate limit has been
configured for the control. Use the command line interface to remove
a rate limit. (29711)
The WebConsole and SNMP MIB incorrectly allow the setting of
reserved IEEE 802.3x full-duplex pause MAC address as the Bridge
Group Address. (28479)
The WebConsole allows the same name for QoS classifiers and
controls. Use unique names for classifiers and controls. (29335)
The WebConsole incorrectly accepts a value outside of the valid range
for the QoS statistical interval. The valid range is from 0 through
4294967295. (25160)
Setting the module baseline does not reset the IP interface statistics in
the WebConsole.
You cannot create multiple IP interfaces with a single VLAN through
the WebConsole. (29611)
4-port GBIC The 4-port GBIC Multilayer Switching Module allows you to create
Multilayer Switching unsupported RMON-2 groups. As a result, these groups appear to be
®
Module (Model configurable through LANsentry , even though you cannot configure
Number 3CB9RG4) them. The RMON groups that are supported on this module are
statistics, history, alarms, and events. (29264)
The bridge port multicast threshold feature on the 4-port GBIC
Multilayer Switching Module forwards two times as many frames as
you specify in the threshold limit. For example, if you specify 1000
frames-per-second as the multicast threshold with the
bridge port
command, the bridge port forwards 2000
multicastLimit
frames-per-second. Use a value that is half the frequency of the
per-second forwarding rate that you want to specify. (29967)
