  • Page 1: Getting Started Guide

    3Com Switch 40x0 Family ® Getting Started Guide 3C17707, 3C17708, 3C17709 http://www.3com.com/ Part No. DUA1770-9AAA05 Published September 2003...
  • Page 2 3Com Corporation reserves the right to revise this documentation and to make changes in content from time MA 01752-3064 to time without obligation on the part of 3Com Corporation to provide notification of such revision or change. 3Com Corporation provides this documentation without warranty, term, or condition of any kind, either implied or expressed, including, but not limited to, the implied warranties, terms or conditions of merchantability, satisfactory quality, and fitness for a particular purpose.

  • Page 3: Table Of Contents

    Accessing Online Documentation Documentation Comments NTRODUCING THE WITCH AMILY About the 3Com Switch 40x0 Family Summary of Hardware Features 3Com Switch 40x0 Family — Front View Detail 1000BASE-SX Ports GBIC Ports SFP Ports 10BASE-T/100BASE-TX/1000BASE-T Ports Console Port LEDs 3Com Switch 40x0 Family — Rear View Detail...
  • Page 4 The Power-up Sequence Powering-up the 3Com Switch 40x0 Checking for Correct Operation of LEDs Choosing the Correct 10/100/1000 Cables Choosing the correct Fiber cables GBIC Operation Approved GBIC Transceivers Inserting a GBIC Transceiver Removing a GBIC Transceiver SFP Operation Approved SFP Transceivers...
  • Page 5 Changing Default Passwords ROBLEM OLVING Solving Problems Indicated by LEDs Solving Hardware Problems Solving Communication Problems Solving Software Upgrade Problems AFETY NFORMATION Power Cord Set — Japan Important Safety Information L’information de Sécurité Importante Wichtige Sicherheitsinformationen OUTS Null Modem Cable PC-AT Serial Cable Modem Cable RJ-45 Pin Assignments...
  • Page 6 NDEX EGULATORY OTICES...

  • Page 7: About This Guide

    Most user guides and release notes are available in Adobe Acrobat Reader Portable Document Format (PDF) or HTML on the 3Com World Wide Web site: http://www.3com.com/...

  • Page 8: Conventions

    BOUT UIDE Conventions Table 1 Table 2 list conventions that are used throughout this guide. Table 1 Notice Icons Icon Notice Type Description Information note Information that describes important features or instructions. Caution Information that alerts you to potential loss of data or potential damage to an application, system, or device.

  • Page 9: Related Documentation

    There are other publications you may find useful: Documentation accompanying the Expansion Modules. Documentation accompanying the GBIC and SFP Transceivers. Documentation accompanying 3Com Network Supervisor. This is supplied on the CD-ROM that accompanies the Switch. Accessing Online The CD-ROM supplied with your Switch contains the following online...

  • Page 10: Documentation Comments

    Please e-mail comments about this document to 3Com at: pddtechpubs_comments@3com.com Please include the following information when commenting: Document title, Document part number (on the title page) and Page number (if appropriate). Example: Part Number DUA1770-9AAA0x, 3Com Switch 40x0 Family Getting Started Guide, Page 21...

  • Page 11: Introducing The 3C Om Switch

    NTRODUCING THE WITCH AMILY ® This chapter contains introductory information about the 3Com Switch 40x0 Family and how it can be used in your network. It covers summary information about the hardware and the following topics: About the 3Com Switch 40x0 Family 3Com Switch 40x0 Family —...

  • Page 12: About The 3Com Switch 40X0 Family

    “Creating an XRN Distributed Fabric” page For more information about 3Com XRN Technology and how to use it in your network, refer to the Implementation Guide on the CD-ROM that accompanies the Switch. For information about using the software features of the Switch, refer to the “Switch Management Interface Reference Guide”...

  • Page 13: Summary Of Hardware Features

    About the 3Com Switch 40x0 Family Summary of Table 3 summarizes the hardware features that are supported by the Hardware Features Switch 40x0. Table 3 Hardware features Feature 3Com Switch 40x0 Family Addresses Up to 12,000 supported Up to 64 permanent entries...

  • Page 14: 3Com Switch 40X0 Family - Front View Detail

    1: I HAPTER NTRODUCING THE WITCH AMILY 3Com Switch 40x0 Figure 1 3Com Switch 4050 — front view Family — Front View Detail Module Unit Status LED 10BASE-T/100BASE-TX/1000BASE-T LEDs Status LEDs and Layer 3 LED Fan LEDs Console Port Temperature...

  • Page 15: 1000Base-Sx Ports

    3Com Switch 40x0 Family — Front View Detail Figure 3 3Com Switch 4070 — front view Module Unit Status LED Status LEDs and Layer 3 LED Fan LEDs Console Port Temperature PSU LEDs Unit LEDs 3Com Switch 4070 Unit Status...

  • Page 16: Sfp Ports

    1: I HAPTER NTRODUCING THE WITCH AMILY SFP Ports The 24 SFP (Small Form Factor Pluggable) ports support fiber Gigabit Ethernet short-wave (SX) and long-wave (LX) SFP Transceivers in any combination. This offers you the flexibility of using SFP transceivers to provide connectivity between the Switch and remote 1000 Mbps workgroups or to create a high capacity aggregated link backbone connection.

  • Page 17: Leds

    3Com Switch 40x0 Family — Front View Detail LEDs Table 4 lists LEDs visible on the front of the Switch, and how to read their status according to color. For information on using the LEDs for problem solving, see “Checking for Correct Operation of LEDs”...
  • Page 18 1: I HAPTER NTRODUCING THE WITCH AMILY Color Indicates Unit Status LED Green The Switch is powered-up and operating normally. Green flashing The Switch is either downloading software or is initializing (which includes running a Power On Self Test). Yellow The Switch has failed its Power On Self Test A port has failed and has been automatically disabled.

  • Page 19: 3Com Switch 40X0 Family - Rear View Detail

    PSU. The Switch 40x0 supports the 3Com AC power supply unit (3C17718). WARNING: The system must not be left without a power supply or a blanking plate in either of the two slots (except during replacement of...

  • Page 20: Power Socket

    The Switch 40x0 supports the 3Com Fan Tray (3C17717). WARNING: A fan tray can be temporarily removed and replaced while the system is running without impacting operations. The system must not be left with either fan tray removed for more than two minutes or damage to the product may be caused.

  • Page 21: Default Settings

    Table 5 shows the default settings for the Switch 40x0. If you initialize one of the Switch units, it is returned to these defaults. Table 5 Default Settings Feature 3Com Switch 40x0 Family Port Status Enabled Port Speed Auto-negotiated Duplex Mode...
  • Page 22 1: I HAPTER NTRODUCING THE WITCH AMILY...

  • Page 23: Installing The Switch

    The Power-up Sequence GBIC Operation SFP Operation WARNING: Safety Information. Before installing or removing any components from any Switch in the 3Com 40x0 Family or carrying out any maintenance procedures, you must read the safety information provided in Appendix A of this guide.

  • Page 24: Package Contents

    8 x screws 4 x rubber feet Choosing a Suitable The 3Com Switch 40x0 is suited for use in an internal wiring closet, a Site network room, or telecommunications room, where they can be mounted in a standard 19-inch equipment rack, or free-standing.

  • Page 25: Rack-Mounting

    Rack-mounting The air is as free from dust as possible. The Switch is situated away from sources of conductive (electrical) dust, for example laser printers. The unit is installed in a clean, air conditioned environment. The AC supply used by the Switch is separate to that used by units that generate high levels of AC noise, for example air conditioning units.

  • Page 26: Placing Units On Top Of Each Other

    Switch, sticking one in the marked area at each corner. Place the Switch units on top of each other. Creating an XRN 3Com Switch 40x0 Family units and the SuperStack 3 Switch 4900 Family Distributed Fabric units can be interconnected to create an XRN Distributed Fabric and then treated as a single manageable unit with one IP address.

  • Page 27: How To Interconnect Units

    Kit or the GBIC Module. The documentation can also be located on the 3Com Web site. Figure 6 Two Switch 4900 units interconnected using the XRN Interconnect Kit...
  • Page 28 HAPTER NSTALLING THE WITCH Only 3Com XRN Interconnect Cables can be used to connect two XRN Interconnect Modules. It is not possible to interconnect the SuperStack 3 Switch 4900 Family and 3Com Switch 40x0 units with any other 3Com device.

  • Page 29: The Power-Up Sequence

    The Power-up Sequence The Power-up The following sections describe how to get your 3Com Switch 40x0 Sequence powered-up and ready for operation. Powering-up the Use the following sequence of steps to power-up the Switch. 3Com Switch 40x0 1 Plug the power cord into the power socket at the rear of the Switch.

  • Page 30: Choosing The Correct Fiber Cables

    See Table 3Com recommends that you use at least Category 5 twisted pair cable — the maximum segment length for this type of cable is 100 m (328 ft). Table 7 Cables required to connect the Switch 4050/4060 to other devices if...

  • Page 31: Gbic Operation

    3CGBIC91 GBIC (SX) 3CGBIC92 GBIC (LX) 3CGBIC97 GBIC (LH70) To access the latest list of approved GBIC transceivers for the Switch on the 3Com Corporation World Wide Web site, enter this URL into your internet browser: http://www.3com.com Inserting a GBIC...
  • Page 32 If the GBIC transceiver is faulty, it will not operate within the Switch. See “Solving Hardware Problems” page 3Com recommends that you only use GBICs supplied by 3Com. If the GBIC transceiver is invalid it will not be recognised by the Switch. Use the following sequence of steps to activate the GBIC ports:...

  • Page 33: Removing A Gbic Transceiver

    SFP Operation Figure 7 Inserting a GBIC Transceiver 3 The transceiver connects to the network using a duplex SC connector. Attach a male duplex SC connector on the network cable into the duplex SC connector on the transceiver. 4 Connect the other end of the cable to a device fitted with an appropriate Gigabit Ethernet connection.

  • Page 34: Inserting An Sfp Transceiver

    If the SFP transceiver is faulty, it will not operate within the Switch. See “Solving Hardware Problems” page 3Com recommends that you only use SFPs supplied by 3Com. If the SFP transceiver is invalid it will not be recognised by the Switch. Use the following sequence of steps to activate the SFP ports:...

  • Page 35: Removing An Sfp Transceiver

    SFP Operation 3 Remove the plastic protective cover if fitted. 4 Connect the fiber cable. Figure 8 Inserting an SFP Transceiver T e m p e r a t u P a c k e t S t a t u s n a b l e d , l i n...
  • Page 36 2: I HAPTER NSTALLING THE WITCH...

  • Page 37: Setting U P For Management

    ETTING P FOR ANAGEMENT Your Switch can operate in its default state, that is, you can install it and it will work straight away (plug-and-play). However, to make full use of the features offered by the Switch, and to change and monitor the way it works, you have to access the management software that resides on the Switch.

  • Page 38: Setting Up Overview

    How do you want to view the automatically How do you want to connect to the Switch? configured IP information? Connect to a front Connect to the console Use 3Com Network Connect to the console panel port and use the port and use the Supervisor (3NS).

  • Page 39: Ip Configuration

    (Static IP addresses are necessary to ensure that the Switch is always allocated the same IP information.) For most installations, 3Com recommends that you configure the Switch IP information manually. This makes management simpler and more reliable as it is not dependent on a DHCP or BootP server, and eliminates the risk of the IP address changing.

  • Page 40: Preparing For Management

    For detailed information about the specific web interface operations and command line interface commands and problem solving, refer to the “Management Interface Reference Guide” on the CD-ROM that is supplied with the Switch or on the 3Com Web site.

  • Page 41: Manually Configuring Ip Information

    Manually Configuring IP Information Manually You can manually configure the Switch IP information in the following Configuring IP ways: Information Connecting to a front panel port — Connect a workstation using an Ethernet cable to a front panel port of the Switch. You can then manually enter IP information using the web interface or the command line interface (CLI).
  • Page 42 3: S HAPTER ETTING P FOR ANAGEMENT Connecting the Workstation to the Switch 1 Connect the workstation to a front panel port using an Ethernet cable as shown in Figure Figure 10 Connecting a workstation to the Switch via a front panel port To connect the cable: a Attach an RJ-45 connector at one end of the Ethernet cable to the Network Interface Card (NIC) in the workstation.
  • Page 43 Manually Configuring IP Information If there is no response, wait for one minute then re-enter the default IP address. 3 At the login and password prompts, enter admin as your user name and press Return at the password prompt (default user name and password). If you have logged on correctly, a set of Getting Started pages are displayed.

  • Page 44: Connecting To The Console Port

    3: S HAPTER ETTING P FOR ANAGEMENT Figure 11 Example top-level command line interface menu 4 At the Select menu option prompt you can either: enter the protocol ip basicConfig command. At the Enter configuration method prompt enter manual. The screen prompts you to enter IP information.
  • Page 45 Manually Configuring IP Information Documentation supplied with the terminal emulation software. A suitable cable: A standard null modem cable — if you are connecting directly to the console port, or A standard modem cable — if you are connecting to the console port using a modem.
  • Page 46 3: S HAPTER ETTING P FOR ANAGEMENT no parity 1 stop bit no hardware flow control Refer to the documentation that accompanies the terminal emulation software for more information. Setting Up the Switch with IP Information You are now ready to manually set up the Switch with IP information using the command line interface.

  • Page 47: Viewing Automatically Configured Ip Information

    IP information automatically assigned to the Switch using the command line interface (CLI). Using 3Com Network You can use the 3Com Network Supervisor application provided on the Supervisor CD-ROM that accompanies your Switch to discover the automatically allocated IP information.

  • Page 48: Connecting To The Console Port

    P FOR ANAGEMENT If your network does not have a DHCP or BootP server, the workstation running 3Com Network Supervisor must be on the same subnet as the Switch, because Auto-IP addresses are non-routable. Connecting to the Alternatively, you can view the automatically configured IP information...
  • Page 49 Viewing Automatically Configured IP Information b Tighten the retaining screws on the cable to prevent it from being loosened. c Connect the other end of the cable to one of the serial ports (also known as a COM port) on your workstation. 2 Open your terminal emulation software and configure the COM port settings to which you have connected the cable.

  • Page 50: Methods Of Managing A Switch

    3: S HAPTER ETTING P FOR ANAGEMENT Figure 15 Example top-level command line interface menu 4 At the Select menu option prompt enter the protocol ip interface summary command. At the Select IP interfaces prompt enter all. A summary of the automatically allocated IP information is displayed.

  • Page 51: Web Interface Management

    You can manage a Switch using any network management workstation running the Simple Network Management Protocol (SNMP) as shown in Figure 19. For example, you can use the 3Com Network Supervisor software that is provided on the CD-ROM that accompanies your Switch.

  • Page 52: Setting Up Command Line Interface Management

    3: S HAPTER ETTING P FOR ANAGEMENT Figure 19 SNMP management over the network Refer to “Setting Up SNMP Management” page Setting Up This section describes how you can set up command line interface Command Line management using a local console port connection or over the network. Interface Management CLI Management via...

  • Page 53: Setting Up Web Interface Management

    Setting Up Web Interface Management 4 To open a Telnet session via the DOS prompt, enter the IP address of the Switch that you wish to manage in the following format: >telnet xxx.xxx.xxx.xxx (where xxx.xxx.xxx.xxx is the IP address of the Switch) If opening a Telnet session via third party software you will need to enter the IP address in the format suitable for that software.

  • Page 54: Web Management Over The Network

    3: S HAPTER ETTING P FOR ANAGEMENT For the browser to operate the web interface correctly, JavaScript and Cascading Style Sheets must be enabled on your browser. These features are enabled on a browser by default. You will only need to enable them if you have changed your browser settings.

  • Page 55: Setting Up Snmp Management

    VLAN 1 (the Default VLAN). By default, all ports on the Switch are in VLAN 1. You can use the 3Com Network Supervisor application that is provided on the CD-ROM that accompanies your Switch to provide SNMP management for your Switch. If you use 3Com Network Supervisor it automatically loads the correct MIBs and necessary files onto your workstation.

  • Page 56: Changing Default Passwords

    3: S HAPTER ETTING P FOR ANAGEMENT Table 9 Default Users User Default Name Password Access Level monitor monitor monitor — the user can view all manageable parameters, except special/security features, but cannot change any manageable parameters. manager manager manager — the user can access and change the operational parameters but not special/security features admin security —...

  • Page 57: Problem Solving

    ROBLEM OLVING This chapter helps you to diagnose and solve problems you may have with the operation of your Switch. There is also an explanation of IP addressing. The topics covered are: Solving Problems Indicated by LEDs Solving Hardware Problems Solving Communication Problems Solving Software Upgrade Problems If you experience a problem that is not listed here, it may be included in...

  • Page 58: Solving Problems Indicated By Leds

    4: P HAPTER ROBLEM OLVING Solving Problems If the LEDs on the Switch indicate a problem, refer to the list of suggested Indicated by LEDs solutions below. The Unit LED does not light Check that the power cable is firmly connected to the Switch and to the supply outlet.
  • Page 59 Solving Problems Indicated by LEDs connecting a working power cord to the ‘problem’ device testing the PSU in the spare slot or another unit installing and testing a second PSU in the ‘problem’ slot If the LED lights flashing red the PSU has shutdown due to over-heating. Solving Hardware Problems page 60 for more advice.

  • Page 60: Solving Hardware Problems

    4: P HAPTER ROBLEM OLVING Solving Hardware In the rare event of your Switch unit experiencing a hardware failure, Problems refer to the list of suggested solutions below. An expansion module is installed and the unit will not power up Ensure that the expansion module is fully seated in the slot and the connectors are engaged so that the securing screws can be tightened.
  • Page 61 Solving Hardware Problems 3 Power cycle the unit. To do this, remove and reconnect the AC mains supply. If the unit has no AC main supply, remove and reconnect the DC RPS supply. If another fan failure warning message is generated via the Command Line Interface or the Web interface, you can replace the fan tray.
  • Page 62 4: P HAPTER ROBLEM OLVING 6 Power cycle the unit. If a further thermal shutdown trap is received, return the unit. An SNMP fan fail trap and email is received 1 If the fail trap is for the front fan tray: a Open the door where the bulge is at the front of the Switch.
  • Page 63 The Switch has identified that the GBIC does not meet the minimum requirements for the Switch and has disabled the port. To correct this problem, completely remove the GBIC and replace it with a 3Com approved GBIC. See “Approved GBIC Transceivers”on...

  • Page 64: Solving Communication Problems

    IP address of the router. The Switch’s IP address has been entered correctly in your network management application (for example 3Com Network Supervisor). The following is an brief overview of IP addressing, and how to obtain a registered IP address.

  • Page 65: Solving Software Upgrade Problems

    If your IP network is internal to your organization only, that is, you do not access the Internet, you may use any arbitrary IP address as long as it is not being used by another device on your network. 3Com suggests you use addresses in the range 192.168.0.0 to 192.168.255.255 with a subnet mask of 255.255.255.0.
  • Page 66 4: P HAPTER ROBLEM OLVING...

  • Page 67: A Safety Information

    You must read the following safety information before carrying out any installation or removal of components, or any maintenance procedures on the 3Com Switch 40x0 Family units. WARNING: Warnings contain directions that you must follow for your personal safety. Follow all directions carefully.

  • Page 68: Important Safety Information

    Important Safety Information WARNING: Installation and removal of the unit must be carried out by qualified personnel only. WARNING: If installing a 3Com Switch 40x0 in a stack with ® SuperStack 3 units that are narrower than the Switch 40x0 Family, the 3Com Switch 40x0 units must be installed below the narrower units.
  • Page 69 † Impédance à la terre. WARNING: U.K. only: If connecting a modem to the console port of the 3Com Switch 40x0 Family, only use a modem which is suitable for connection to the telecommunications system. WARNING: RJ-45 Ports. These are shielded RJ-45 data sockets. They cannot be used as standard traditional telephone sockets, or to connect the unit to a traditional PBX or public telephone network.
  • Page 70 A: S PPENDIX AFETY NFORMATION WARNING: Fiber Optic ports - Optical Safety Never look at the transmit laser while it is powered-up. Never look directly at the fiber ports and fiber cable ends when they are powered-up. WARNING: Use of controls or adjustments of performance or procedures other than those specified herein may result in hazardous laser emissions.

  • Page 71: L'information De Sécurité Importante

    AVERTISSEMENT: Si vous entassez l'unité Switch avec les unités ® SuperStack 3 Hub, l'unité de la gamme des Switch 3Com 40x0 doit être installée en dessous des unités Hub plus étroites. AVERTISSEMENT: Vous devez mettre l’appareil à la terre (à la masse) ce groupe.
  • Page 72 A: S PPENDIX AFETY NFORMATION AVERTISSEMENT: La prise secteur doit se trouver à proximité de l’appareil et son accès doit être facile. Vous ne pouvez mettre l’appareil hors circuit qu'en débranchant son cordon électrique au niveau de cette prise. AVERTISSEMENT: L’appareil fonctionne à une tension extrêmement basse de sécurité...
  • Page 73 AVERTISSEMENT: Avant d’installer le éventez le porteur, lisez les informations relatives à la sécurité qui se trouvent dans le guide d’utilisation (de la gamme des Switch 3Com 40x0). AVERTISSEMENT: Un support de ventilateur peut être démonté provisoirement et remplacé pendant le fonctionnement du système sans que cela n’ait d’influence sur le fonctionnement.

  • Page 74: Wichtige Sicherheitsinformationen

    Fachpersonal erfolgen. VORSICHT: Wenn die Switch 40x0 Einheit in einer Stapel mit anderen ® SuperStack 3 Hub Einheiten eingebaut werden soll, muß der 3Com Switch 40x0 Reihe Einheit unter die schmaleren Hub Einheiten eingebaut werden. VORSICHT: Das Gerät muß geerdet sein.
  • Page 75 Leistungen und Verfahren in anderer als der hierin genannten Weise kann zu gefährlichen Laseremissionen führen. VORSICHT: Bevor Sie den PSU hinzufuegen, lesen Sie die Sicherheitsanweisungen, die im Handbuch aufgefuehrt sind (3Com Switch 40x0 Reihe). VORSICHT: Die PSU muss vor dem Ausbauen von der Stromversorgung getrennt werden.
  • Page 76 AFETY NFORMATION VORSICHT: Bevor Sie den hinzufuegen steinbrecherfan, lesen Sie die Sicherheitsanweisungen, die im Handbuch aufgefuehrt sind (3Com Switch 40x0 Reihe). VORSICHT: Ein Lüfterträger kann vorübergehend ausgebaut und ersetzt werden, während das System läuft, ohne dass dabei der normale Betrieb beeinträchtigt wird.

  • Page 77: B Pin - Outs

    OUTS Null Modem Cable 9-pin to RS-232 25-pin PC-AT Serial Cable 9-pin to 9-pin...

  • Page 78: Modem Cable

    B: P PPENDIX OUTS Modem Cable 9-pin to RS-232 25-pin RJ-45 Pin Pin assignments are identical for 10/100 and 1000 RJ-45 connectors. Assignments Table 10 Pin assignments Pin Number 10/100 1000 Ports configured as MDI Transmit Data + Bidirectional Data A+ Transmit Data + Bidirectional Data A- Receive Data +...
  • Page 79 RJ-45 Pin Assignments Table 11 Pin assignments Pin Number 10/100 1000 Ports configured as MDIX Receive Data + Bidirectional Data B+ Receive Data - Bidirectional Data B- Transmit Data + Bidirectional Data A+ Not assigned Bidirectional Data A- Not assigned Bidirectional Data D+ Transmit Data Bidirectional Data D-...
  • Page 80 B: P PPENDIX OUTS...

  • Page 81: Specifications

    –10 ° to +70 °C (14 ° to 158 °F) Operating Humidity 10–95% relative humidity, non-condensing Standards EN60068 to 3Com schedule (package testing: paras 2.1, 2.2, 2.30 and 2.32. Operational testing: paras 2.1, 2.2, 2.30 and 2.13. Safety Agency Certifications UL 60950, EN60950, CSA 22.2 No.
  • Page 82 C: T PPENDIX ECHNICAL PECIFICATIONS...

  • Page 83: Upport For Your

    Contact your authorized 3Com reseller or 3Com for additional product and support information. Troubleshoot You will find support tools posted on the 3Com web site at Online http://www.3com.com/ 3Com Knowledgebase helps you troubleshoot 3Com products. This query-based interactive tool is located at and contains thousands of http://knowledgebase.3com.com...

  • Page 84: Access Software Downloads

    Software Updates are the bug fix / maintenance releases for the version Downloads of software initially purchased with the product. In order to access these Software Updates you must first register your product on the 3Com web site at http://eSupport.3com.com/ First time users will need to apply for a user name and password.
  • Page 85 Telephone Technical Support and Repair To send a product directly to 3Com for repair, you must first obtain a return authorization number (RMA). Products sent to 3Com, without authorization numbers clearly marked on the outside of the package, will be returned to the sender unopened, at the sender’s expense. If your...
  • Page 86 Telephone Number Latin America Telephone Technical Support and Repair Antigua 1 800 988 2112 Guatemala AT&T +800 998 2112 Argentina 0 810 444 3COM Haiti 57 1 657 0888 Aruba 1 800 998 2112 Honduras AT&T +800 998 2112 Bahamas...
  • Page 87 NDEX installing the Switch 23 access levels of default users 55 prerequisites 25 automatic setup 47 3Com Network Supervisor 47 interconnect cable 27 console port 48 IP addressing registered 64 IP configuration 39 cable 10/100/1000 29 fiber 30 LEDs 17...
  • Page 88 NDEX communication problems 64 hardware problems 60 IP addressing 60 LEDs 58 rack mounting a Switch 40x0 Family 25 safety information English 68 French 71 German 74 Operation 33 ports 16 transceivers 33 Simple Network Management Protocol. See SNMP SNMP 55 SNMP management 51 setting up 55 specifications, system 81...
  • Page 89 You must only insert a 3Com approved GBIC or SFP transceiver into the Switch. These are listed in the “Approved GBIC Transceivers” or "Approved SFP Transceivers" section of the Getting Started Guide.
