Corrected Problems
in Release 3.0.0

System

Bridging

Virtual LANs (VLANs)

QoS

Roving Analysis

Web Console

Ethernet

I M S
SSUES FOR ULTILAYER
This section describes the problems that were corrected for Multilayer
Switching Modules in software Releases 3.0.0 and 3.0.1.
Multilayer switching modules no longer return erroneous MBA
diagnostic failure messages. (29211)
Spanning Tree Bridge Protocol Data Units (BPDUs) are no longer
dropped during high broadcast levels. (26230)
Previously, in some configurations, the system did not allow you to
define the proper number of VLANs, causing out-of-resource
messages. The system now allows correct VLAN definitions. (27137)
IP Multilayer switching modules now advertise statically defined routes in
RIP updates. (27000)
User Datagram Protocol (UDP) Helper now works for ports 137
through 139 WINS packets. (27359 and 27929)
In rare instances, Dynamic Host Configuration Protocol (DHCP) clients
were unable to get an IP address. This has been fixed. (25748)
The problems that caused Quality of Service (QoS) drop controls to fail
have been fixed. (26950)
The system forwards IEEE 802.1Q tagged frames properly to the
roving analysis monitor ports.
The WebConsole now supports the new Administration Console
menu item in IP RIP. (25663)
password
Whenever a non-switch fabric module is reset (with the
nvData reset
doing a warm reset, by running service diagnostics, and so forth) or
whenever a backplane port is disabled and then reenabled, the links
to the switch fabric module no longer go down on some occasions
and are now always reestablished. (30063)
M
WITCHING ODULES
command, by inserting the module into a chassis, by
module
