Code Text on
seven LCD of control panel
segm. CDP 312
display (or DRIVES WINDOW)
A 115 15 CURR RIPP
A 118 18 MAIN UVLT
A 120 20 CURR DEV
A 123 23 MOT2 TEMP
A 124 24 MOT2 LOAD
A 125 25 NO ACK
A 126 26 CONV FAN
DCS 600 Operating Instructions
Definition /
Possible source
Armature current ripple
One or several thyristors carry no current.
Check: - Current feedback with oscilloscope
(6 pulses within one cycle visible?);
- Branch fuses, thyristor gate con-
nection and gate-cathode resis-
tance;
- See also parameters
[P 43.11], and [P 43.12]
Alarm: Mains Undervoltage (AC)
Setting of undervoltage monitoring with Pa-
rameter or/and
[P 40.01]
Check: - See also Fault Code
Alarm: Armature Current Deviation
If the current reference ARM_CUR_REF
deviates from the current feedback
[P 3.12]
for more than 5 sec by more than 20 %,
referenced to the rated current, this signal
will be shown.
Check: - Ratio between mains supply
voltage and EMF
Alarm: Overtemperature MOTOR 2
Check: - Parameter setting
correct?
See also Fault Code
Alarm: Overload MOTOR 2 (Thermal Model 2)
Check: - Overload of motor
- Parameter setting
correct?
Alarm: No Acknowledge DC Break or Dyna-
mic Brake contactor
Check: - Digital inputs
Alarm: No (Thyristor Power) Converter FAN
Acknowledge
Check: - See Fault Code
Chapter 4 - Signals and Troubleshooting
[P 43.10],
[P 40.02]
.
F 29
[P 28.13]
F 6.
[P 28.07]
[P 15.18], [P 15.20]
F 50.
Remark
Signal
number
(ALARM_WORD_1/2)
9.05 bit 0
9.04 bit 10
9.04 bit 13
9.04 bit 8
9.04 bit 9
9.04 bit 2 RUN =
blocked
9.04 bit 12
4 - 13
IV F
