• Programmable values (can be changed for monitoring of other signals)
Cyclic transmission time for the first three programmable values is every 2 ms, for all
other values every 8 ms:
Cyclic transmission
-->
from
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
CON-2 --> AMC
CON-2 --> AMC
CON-2 --> AMC
CON-2 --> AMC
CON-2 --> AMC
CON-2 --> AMC
CON-2 --> AMC
CON-2 --> AMC
CON-2 --> AMC
CON-2 --> AMC
CON-2 --> AMC
For example:
DCS 600 Operating Instructions
Enter pa-
to rameter in
95.01
95.02
95.03
95.04
95.05
95.06
95.07
95.08
95.09
95.10
95.11
95.12
95.13
94.01
94.02
94.03
94.04
94.05
94.06
94.07
94.08
94.09
94.10
94.11
Display of actual field current value 3.19 in 8 ms ⇒ 94.11 = 3.19.
Then call for display of Parameter 3.19.
Chapter 2 - Start-Up Instructions
Cyclic trans- Default
mission time
2 ms 3.11 CURRENT REF
2 ms 45.01 FLUX REF
2 ms 45.03 EMF REF
8 ms 0
8 ms 0
8 ms 0
8 ms 0
8 ms 0
8 ms 0
8 ms 0
8 ms 0
8 ms 0
8 ms 0
2 ms 3.13 ARM ALPHA
2 ms 1.15 CONV CUR
2 ms 3.12 CUR REF3
8 ms 1.11 RL MAINS VOLT ACT
8 ms 1.13 RL ARM VOLT ACT
8 ms 1.28 LOAD CUR ACT FILT
8 ms 1.17 RL EMF VOLT ACT
8 ms 1.24 HEATSINK TEMP
8 ms 1.20 MOT1 CALC TEMP
8 ms 3.17 FIELD CUR REF M1
8 ms 3.19 REL FIELD CUR M1
2 - 5
