DCS 600 and Modbus PLUS

Hardware
DCS 600
NMBP-01
Cable
Associated publications
DCS 600
Modbus
PLUS
Software settings
DCS 600
Drive
Parameter
51.01
51.02
51.03
51.04
51.05
51.06
51.07
51.08
51.09
51.10
DCS 600 Operating Instructions
SDCS-AMC-DC classic board
Software 1.3
length 0.2 ... 10 m
Technical Data
Software Description
DC Converter Fieldbus
Database
NMBP-01
Database
Parameter
Default connected
parameters
Fieldbus Parameter Name
Par. No.
1 MODULE TYPE
2 MODULE MODE
3 DRIVE NUMBER
4 GOOD MESSAGES
5 BAD MESSAGES
6 GLOBAL DATA OUT 1
7 GLOBAL DATA OUT 2
8 GLOBAL DATA OUT 3
9 GDATA IN 1STATION
10 GDATA IN 1WORD
To be continued!
plastic optical fibre
3ADW000054R0301
3ADW000076R0401
3ADW000097R0101
GLOBAL\DEIND\DEIND051.NSF
3AFY58919802R0125RevB
GLOBAL\FIDRI\FIDRI002.NSF
98.02 =
70.01 =
70.02 =
70.20 =
Main control word
Speed reference
Main status word
Motor speed
Select
MODBUS PLUS
0
2 to 64
0 to 32767
0 to 32767
1
0 to 6
0 to 6
1 to 64 PLC station No.
1
Chapter 2 - Start-Up Instructions
ABB Lampertheim
ABB Lampertheim
ABB Lampertheim
(not on database)
ABB Helsinki
2 (FIELDBUS)
1
Optical power/cable length
(use default)
1
(data set 1/1)
(data set 1/2)
(data set 2/1)
(data set 2/2)
= Self-adjustment while switching on
IV F
2 - 31
