ABB DCS 600 MultiDrive Operating Instructions Manual page 75

Code Text on
seven LCD of control panel
segm. CDP 312
display (or DRIVES WINDOW)
 *)
M/F LINK
 *)
PANEL LOSS
 *)
EXT FAULT
 *)
SW MISMATCH
*) No Fault Code available on seven segment display!
DCS 600 Operating Instructions
Definition /
Action
Communication fault in the Master-Follower-
link
this signal has to be effective only as
If
an alarm (warning) signal, the mode of
functioning can be changed by setting
the parameter
CH2_COM_LOSS_CTRL
[P 70.14].
Check: - Optical fibre cable connections.
Connection fault to the Control Panel
CDP 312 or DRIVES WINDOW
Check: - Control Panel CDP 312 discon-
nected?
- Connection adapter or cable
damaged?
- Communication problems using
the program DRIVES WINDOW in
"LOCAL" mode?
External fault at binary input (DI) selected by
Parameter [P 15.23]
An external fault is activated by a "Low sig-
nal" at the binary input (DI) selected by Pa-
rameter
[P 15.23].
Software versions loaded to SDCS-CON-2 and
SDCS-AMC-DC do not match
see DCS 600 Software release notice
Chapter 4 - Signals and Troubleshooting
(FAULT_WORD_
Remark
Status
signal
1/2/3)
9.06 bit 11
9.06 bit 13
9.02 bit 9
9.06 bit 9
4 - 11
IV F
