Presetting of the EMERGENCY STOP function via binary input DI5:
Connection of this signal has to correspond with the configuration of a fail-safe-
circuit, i.e. if the signal applied to DI5 is "0" (parameter 12.16 EME STOP SEL is set to
DI5), the EMERGENCY STOP function will operate (will be activated).
13.12 = INVERTED
Inverting the incoming signals
21.04 = e.g. COAST STOP
The drive will coast to stop with this setting
22.04 = e.g. 1 ⇒ 1 sec
Setting of the ramp time with EMERGENCY STOP function provided that the
Parameter 21.04 = RAMP STOP has been selected
Input of data concerning the connected I/O boards:
98.08 = Make settings which correspond to the hardware configuration used.
Input of data is necessary as the software will check the availability of the I/O
bords as specified by settings.
Input of motor data and line voltage:
41.03 = Rated motor field current
Max. field current of the motor as indicated on rating plate. This is used to scale
those parameters referring to the motor field current, such as field current limitation
and field current monitoring.
42.06 = Rated line voltage
This is used to scale those parameters referring to the line voltage, such as line
undervoltage.
99.02 = Rated motor voltage
Scaling speed for speed control with EMF feedback.
99.03 = Rated motor current
This is used to scale those parameters referring to the rated motor current, such
as current limitation or torque limitation.
99.05 = Speed at field weakening point
Maximum speed of motor within armature control range and flux control.
Scaling speed for speed control with EMF feedback.
Note: Calculation of the nominal torque 4.22 is based on this parameter.
41.19 = Int EMF REF
Reference for voltage control in field weakening range.
50.01 = Speed scaling
Speed of the motor to be scaled to 20 000.
This scaling is used for overriding control and for internal dataprocessing, i.e.
scaling of the speed dependent parameters, such as min. and max. values.
Note 1: The Speed scaling must be set in the range of 87%...500% of the mo-
Note 2: The Software DRIVES WINDOW and the Control Panel CDP 312 will
DCS 600 Operating Instructions
tor nominal speed (99.05).
always display physical units!
