Chapter 2 - Start-Up Instructions
DCS 600 and Modbus PLUS: Software settings (continued)
Drive
Parameter
51.11
51.12
51.13
51.14
Note: After change of Parameters Group 51 switch OFF and ON the DCS 600 and the
Fieldbus adapter!
Modbus
PLUS
Example for switch-on sequence
Send to control word 7.01
Note: Before receiving the first dataset the drive sets the CH 0 alarm status
2 - 32
IV F
Parameter Name
Fieldbus
Par. No.
11 GDATA IN 2STATION
12 GDATA IN 2WORD
13 GDATA IN 3STATION
14 GDATA IN 3WORD
Control word
(send to drive)
Select
0 to 64
0 to 31
0 to 64
0 to 31
7.01 = bit10
0476H (ON = 0; READY, if there is no failure)
0477H (main contactor ON)
047FH (RELEASE for speed and current control)
= Self-adjustment while switching on
= 1
