Internal signal connections
The software of the units series DCS 600 is divided into two parts which are handled
by processors integrated in the respective boards
SDCS-AMC-DC (Software 15.6xx)
The upload of signals from SDCS-CON-2 to SDCS-AMC-DC board are operated by:
• 6 automatic channels
• 11 programmable channels, selectable in group 94 (see Software description - chapter
31)
The 6 automatic channels are used by the functions:
• Display signals at control panel CDP 312
• Monitor signals at DriveWindow Tool
• Data Logger at DriveWindow Tool
If
• more than 6 signals of the SDCS-CON-2 board are selected, or
• the function Signals and Parameter of DriveWindow, or
• the overriding control (AC 80, AC 70...)
is used for monitoring, the signals should be selected in group 94.xx
Note: In the below mentioned tables
instead of
•
Fixed (defined) values
Cyclic transmission is used for fixed values. Fixed values are:
Cyclic transmission
-->
from
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
AMC --> CON-2
DCS 600 Operating Instructions
.
SDCS-AMC-DC / SDCS-CON-2
Parameter
to


2.13
5.06
5.07

SDCS-CON-2 (Software 15.2xx)
will be used as type designations
AMC / CON-2
.
Function
Internal Control Word
Reserved
Torque reference value
Analogue output 1
Analogue output 2
Local reference 3
Chapter 2 - Start-Up Instructions
Cyclic trans-
mission time
2 ms
2 ms
2 ms
2 ms
2 ms
8 ms
IV F
and
2 - 3
