Board Specifications

Dimensions (Extended Height PCIe Form-Factor)

Height: 7.477 inches (18.992 cm)
Length: 9.50 inches (24.13 cm) (¾ PCIe length)
Thickness: 66.87 mil ±10% (1.698 mm ±10%)
Note: Reserve two adjacent PCIe slots to accommodate fan-sink height.
Note: A 3D model of this board is not available.
See the VCK190 evaluation board

Environmental

Temperature
Operating: 0°C to +45°C
Storage: -25°C to +60°C
Humidity
10% to 90% non-condensing
Operating Voltage
+12 V
DC
UG1366 (v1.0) January 7, 2021
VCK190 Board User Guide
website for the XDC listing and board schematics.
