APPENDIX C - ANALOG INPUT RANGES (LOW PRESSURE CHILLERS)

The following table indicates the valid display range
for each of the analog sensor input parameters for low
pressure chillers. In the event that the input sensor is
reading a value outside of these ranges, the less than
(<) or greater than (>) symbols will be displayed beside
the minimum or maximum value, respectively.

TABLE 14 - ANALOG INPUT RANGES (LOW PRESSURE CHILLERS)

ANALOG INPUT
Leaving Chilled Liquid Temperature (RT1)
Return Chilled Liquid Temperature (RT9)
Leaving Condenser Liquid Temperature (RT4)
Return Condenser Liquid Temperature (RT5)
Evaporator Refrigerant Temperature (RT7)
Discharge Temperature (RT2)
Oil Temperature (RT3)
Condenser Pressure (CPT)
Condenser Temperature (R11)* (RT17)
Condenser Temperature (R123)* (RT17)
Evaporator Pressure (EPT)
Evaporator Temperature (R11)* (RT7)
Evaporator Temperature (R123)* (RT7)
Oil Sump Pressure (LOP)
Oil Pump Pressure (HOP)
Purge Pressure (PPT)
Drop Leg Refrigerant Temperature (RT6)
Bearing Temperature (RT15, RT16)
Refrigerant Level (Future)
*Calculated values when represented as a saturation temperature. They will display XXX if the pressure used for the calculation is out of range.
JOHNSON CONTROLS
ENGLISH RANGE
LOW HIGH UNITS
0.0 82.0 °F
0.0 94.1 °F
8.0 133.5 °F
8.0 133.5 °F
0.0 126.1 °F
19.0 226.3 °F
19.0 226.3 °F
2.5 35.3 PSIA
-1.4 124.2 °F
7.2 130.1 °F
0.0 12.5 PSIA
-31.2 66.8 °F
-22.4 74.2 °F
2.9 20.9 PSIA
14.3 78.2 PSIA
0.0 100.0 PSIA
0.0 121.8 °F
30.0 250.0 °F
0.0 100.0 %
METRIC RANGE
LOW HIGH UNITS
-17.7 27.7 °C
-17.7 34.5 °C
-13.3 56.3 °C
-13.3 56.3 °C
-17.7 52.3 °C
-7.2 107.9 °C
-7.2 107.9 °C
17.2 243.4 KPAA
-18.5 51.2 °C
-13.7 54.5 °C
6.9 86.2 KPAA
-35.7 19.3 °C
-30.2 23.4 °C
20.0 144.1 KPAA
98.6 539.2 KPAA
6.9 689.5 KPAA
-17.7 49.8 °C
-1.1 121.1 °C
0.0 100.0 %
