TABLE 13 - PROGRAMMABLE SETPOINT VALUES (CONT'D)
SETUP SCREEN
SETPOINT
Set Date
Set Time
Clock
12/24 Hr (Clock Mode)
SCHEDULE SCREEN (SETUP SUBSCREEN)
SETPOINT
Schedule
Schedule Data: Sunday through Saturday, Start Time
and Stop Time, Standard Week and six Exception
Weeks
Repeat Sunday
Repeat Exceptions
USER SCREEN (SETUP SUBSCREEN)
SETPOINT
Data Display Mode
User ID (ID 1 through 4)
User Password (ID 1 through 4)
User Level (ID 1 through 4)
COMMS SCREEN (SETUP SUBSCREEN)
SETPOINT
Chiller ID
Baud Rate (Printer Setup and COM 2)
Data Bits (Printer Setup and COM 2)
Parity (Printer Setup)
Parity (COM 2)
Stop Bits (Printer Setup and COM 2)
JOHNSON CONTROLS
APPENDIX B - PROGRAMMABLE SETPOINT VALUES
ACCESS MINIMUM
LEVEL VALUE
Operator 16/01/1963
12:00 AM or
Operator
00:00
Operator Disable
Operator 12 Hr Mode
ACCESS MINIMUM
LEVEL VALUE
Operator Disabled
12:00 AM or
Operator
00:00
Operator No
Operator No
ACCESS MINIMUM
LEVEL VALUE
Operator English or Metric
Service 1
Service 0
Service 0 - View, 1 - Operator, 2 - Service
ACCESS MINIMUM
LEVEL VALUE
Operator 0
1200, 2400, 4800, 9600, 19200,
Operator
38400, 57600
Operator 5 Bits, 6 Bits, 7 Bits, 8 Bits
Operator None, Odd, Even
Operator None, Odd, Even
Operator 1 Bit
MAXIMUM
DEFAULT
VALUE
01/01/4000 01/01/1999
11:59 PM or 12:00 AM or
23:59 00:00
Enable Enable
24 Hr Mode 12 Hr Mode
MAXIMUM
DEFAULT
VALUE
Enabled Disabled
11:59 PM or 12:00 AM or
23:59 00:00
Yes No
Yes No
MAXIMUM
DEFAULT
VALUE
English
9999 1
9999 0
0
MAXIMUM
DEFAULT
VALUE
255 0
19200
8 BIts
None
Odd
2 Bits 1 Bit
